| Model | GE-T Series |
| Working Area | 1500*3000mm |
| Laser Power | 500W/750W/1000W/2000W Raycus |
| Laser Wave Length | 1064nm |
| Working Table | Saw tooth |
| Maximum Idle Running Speed | 1200mm/s |
| Position Accuracy | ±0.05mm/m |
| Position Speed | 60m/min |
| Minimum Line Width | ± 0.02mm |
| Cutting Thickness | ≤6mm |
| Software and Control System | NC Editor (Optional Cypcut) |
| Position Type | Red DOT |
| Power Consumption | ≤12KW |
| Working Voltage | 110-220V,380V/50-60Hz |
| Auxiliary Gas | Oxygen, nitrogen, air |
| Air Proportional Valves | For power 1000W and higher |
| Working life of fiber module | More than 100000 hours |
| Fiber laser cutting head | WEIHONG or Raytools |
| Software | Compatible with various formats |
| Computer | Yes |
| Water cooling system | S&A industry chiller |
| Motor | Japan Yasakawa two 850W Y motors + 850W X motor |
| Driver | Yasakawa 1000W |
| Reducer | Shimpo/ ASG From Japan |
| Liner guider system | Taiwan HIWIN |
| Rack gear transmission | YYC Precision double rack drive |
| Electric component | made in France |
| Weight | 3700Kgs |
| Big safety cover | Optional |
| Add Tube cutter | Optional |
