| US$211,150.00-246,000.00 | 1 Piece (MOQ) |
| Overall dimension | |
| Overall width of upper assembly(A) | 2990mm |
| Overall width(B) | 3340mm |
| Overall height of cab(C) | 3190mm |
| Tail swing radius(D) | 3500mm |
| Overall height of engine hood(E) | 2700mm |
| Ground clearance of counterweight (F) | 1210mm |
| Wheelbase (G) | 4240mm |
| Crawler length (H) | 5180mm |
| Crawler gauge (I) | 2740mm |
| Crawler pad width (J) | 600mm |
| Min. ground clearance (K) | 500mm |
| Overall length (L) | 11020mm |
| Overall height of boom (M) | 3580mm |
| Overall parameters | |
| Bucket capacity | 2.0m³ |
| Overall operating weight | 40050kg |
| Max. excavation force | 236KN |
| Slew speed | 0-10.3r/min |
| Traveling speed (low/high) | 3.4/5.3km/h |
| Average ground pressure | 69.4kPa |
| Max. digging radius | 10610mm |
| Max. digging depth | 6850mm |
| Max. digging height | 10170mm |
| Max. dumping height | 7090mm |
| Min. front slewing radius | 4380mm |
| Engine | |
| Model | SD130A |
| Type | Water-cooled, Four-stroke,supercharged |
| Rated Power@Revolution Speed | 215kw/1700r/min |
| Displacement | 12800mL |
| Cylinder bore × stroke | 131*158mm |
| Emission standard | GB20891-2014 China Phase III |
| Traveling/swing system | |
| Qty. of carrier rollers (single side) | 2 |
| Qty. of track rollers (single side) | 9 |
| Traveling brake type | Wet disc brake |
| Swing mode | Hydraulic drive internal tooth single-row ball-bearing |
| Swing brake type | Wet disc brake |
| Hydraulic system | |
| Hydraulic control type | Pilot proportional control valve |
| Hydraulic system type | dual pump constant power negative flow control system |
| Max. flow | 2*300+25.5L/min |
| Main pump model | K3V180 |
| Operating pressure | 320/350kgf/cm2 |
| Main valve model | KMX32N |
| Arm cylinder - cylinder bore× diameter of piston rod × stroke | 1-175*115*1700mm |
| Boom cylinder - cylinder bore× diameter of piston rod × stroke | 2-160*105*1530mm |
| Bucket cylinder - cylinder bore× diameter of piston rod × stroke | 1-145*100*1285mm |
| Fill capacity | |
| Fuel | 620L |
| Engine oil | 45L |
| Hydraulic oil | 515L |
| Antifreeze | 2×6.8L |
| Swing reducer | 6.0L |
