| US$5,300.00-8,500.00 | 1 Piece (MOQ) |
| SPECIFICATIONS | ZQ3050X16 |
| Max. drilling dia(mm) | 50 |
| Distance from spindle nose to table surface(mm) | 330-1200 |
| Spindle center to column generating distance | 350-1520 |
| Spindle travel (mm) | 200 |
| Spindle Cone | 5 |
| Range of spindle speeds(r.p.m) | 78,135,250,350,590,1100 |
| Spindle speed series | 6 |
| Spindle feeding range(r.p.m) | 0.1-0.56 |
| Spindle feeding step | 6 |
| Rocker rotary angle | ±90° |
| Main motor power (kw) | 4 |
| Movements motor power(kw) | 1.5 |
| Machine weight kgs | 2500 |
| Overall dimensions(mm) | 2170x950x2450 |
