Best Quality High Frequency Welding Pipe Forming Machine

US$190,000.00-230,000.00 1 Set (MOQ)

Basic Info.

Model NO.

ZY-HF76

Pipe Material

Carbon Steel

Condition

New

Customized

Theory

Inverter

Application

Industry, Decoration

Type

Pipe Production Line

Diameter

25-127mm

Wall Thickness

1.2-4.0mm

Speed

0-70m/Min

Main Motor

132kw

H.F.Welder

300kw

Weight

37.89t

Transport Package

Shipping, Rain-Proof Package

Specification

60m*5.5m*2.5m

Trademark

Zhangyun Machinery

Origin

Zhangjiagang City

HS Code

8515219000

Production Capacity

200 Sets/Year

Product Description

Best Quality High Frequency Welding Pipe Forming Machine

Equipment Specifications

Item	Wall Thickness (mm)	Max. Speed (m/Min)	Main Motor (kw)	H.F.Welder (kw)	Width of Rolled Strip	Thickness of Rolled Strip
ZY-HF16	0.3~1.0	90	22	60	22~55mm	0.3~1.0mm
ZY-HF20	0.4~1.5	90	45	100	30~90mm	0.4~1.5mm
ZY-HF32	0.6~1.8	90	75	100	40~120mm	0.6~1.8mm
ZY-HF45	0.6~2.0	80	90	150	50~160mm	0.6~2.0mm
ZY-HF50	0.8~3.0	70	132	200	60~200mm	0.8~3.0mm
ZY-HF60	0.8~3.0	70	90*2	200	60~240mm	0.8~3.0mm
ZY-HF76	1.2~4.0	70	132*2	300	90~280mm	1.2~4.0mm
ZY-HF89	1.2~4.5	70	132*2	300	100~330mm	1.2~4.5mm
ZY-HF114	1.5~4.0	55	160*2	300	100~400mm	1.5~4.0mm
ZY-HF125	1.5~6.0	50	200*2	400	150~410mm	1.5~6.0mm
ZY-HF165	2.0~6.0	50	200*2	500	150~520mm	2.0~6.0mm
ZY-HF219(6mm)	2.0~6.0	40	200*2	500	350~700mm	2.0~6.0mm
ZY-HF219(8mm)	3.0~8.0	40	250*2	600	270~700mm	3.0~8.0mm

Zhangjiagang City Zhangyun Machinery Manufacturing Co., Ltd. is established in 2002, manufacturer of elevator guide rail processing production line machinery, cold roll forming line machinery and high frequency welding line machinery.
Quality Oriented,Technology Innovation is our core concept. Each component of our machines is examined and qualified before assembling; each set of our equipment is fully test run before delivery.
