| US$350,000.00-700,000.00 | 1 Set (MOQ) |
| Working width:2200mm; Max. mechanical speed:200m/min Economic speed:150-180m/min | |
Name | Configuration |
| HS-C HS-C Hydraulic Mill Roll Stand | ,,,,,. Hyperbolic heavy rocker arm, expansion type head, multi-point brake, hydraulic drive lifting, left and right moving, centering. ,8000mm,. Electric trolley, rail length 8000mm, medium plate welding. |
Auto splicer | ,.200m/min,0-100m/min,1. Keep continuous running for reducing paper waste during shutdown. Liner speed: 200m/min, splicing speed: 0-150m/min, about 1second for splicing. |
| SF-FW20 SF-FW20 Single Facer | ,,Ø380mm,,,,,,,PLC. With modular type fast changing assembly, the flute roller diameter Ø380mm in tungsten coated, foreign famous-brand bearing, universal joint transmission, frequency motor, glue width electrical adjustment, PLC auto control glue amount. |
| ,, | |
| TO-B TO-B Double-layer Heavy Overbridge | ,,,,,,. Frequency drive paper puller, heavy channel steel, single-corrugated paper storage section in wave shape, adsorption expansion, electrical correction, one set of control panel over and under the bridge, convenient for operation |
| PH-B PH-B Core-paper Pre-heater | Ø1000mm,320°,. Ø1000mm, with preheated wrap angles electrically adjusted in 320°, including the pressure vessel certificate. |
| PH-B PH-B Corrugated-paper Pre-heater | Ø1000mm,320°,. Ø1000mm, with preheated wrap angles electrically adjusted in 320°, including the pressure vessel certificate. |
| PH-B PH-B Three-roller Pre-heater | Ø1000mm,320°,. Ø1000mm, with preheated wrap angles electrically adjusted in 320°, including the pressure vessel certificate. |
| PM-20 PM-20 Double-roller Pasting Machine | Ø360mm,,,,,PLC Gluing roller Ø360mm, with shaft loading; Each layer has independent frequency conversion drive, synchronous belt transmission, with man-machine touch screen and PLC automatic speed-tracking control glue amount |
| DF-D DF-D Double Facer | :600mm×16,,,,. Bonding & Drying section: heating plates 600mm*16pcs, drying part pressed by touch plates, auto lifting cotton belts, pneumatically tension and auto correction. :4000mm,,. Cooling & Forming section: length 4000mm, the upper belt pressed by touch plates with auto correction. :,Ø740mm,. Driving part: Universal joint drive, driving roller Ø740mm. The whole machine has thermal insulation shield. |
Thin-blade Slitter Scorer | ,,610 General configuration, designed in lifting type with 6 blades & 10 scorers |
| RC-C RC-C NC Double-layer Helical-knife Cutoff | ,,,15,12mm,±1mm. It's designed in double-layer helical knife, adopted American brand EMERSON servo drive, permanent magnet servo motor, 15-inch touch screen display, with max. sheet feeding thickness of helical knife 12mm and max. cutting error ±1mm. |
| LM-20B LM-20B Fully-auto Double-layer Gantry Stacker | ,,,,,,,. Double-layer gantry, can auto stacking, feeding, counting and zero returning, the gantry lifting stacking can electrically position the baffling plate and auto transverse output. |
Glue-making system | ,,,,. It consists of carrier tank, main tank, storage tank, single machine glue circulating box and circulating pump, with pipeline provided by customers. |
