Two Platen Injection Machine Z/1300

Product Description

Z Series / Two Platen IMM According to product demand , easy to customize opening stroke Mold opening & clamping with agility and stability , which has improved cycle time Increase the service life and reduce maintenance cost With strong stiffness of frame platen , which can reduce the floor area Open stroken & mold thickness can be increased within permitted / feasible rang The ejector rod can be lenghtened PID temperatureControl of mold hot runner Overlap functiong of plasticizing & charging can be done when in mold open or mold eject stage Specification of clamping & injection unit can be changed flexibly / combination machine can made to order European & American Design Mature Structure Create Core Value for Customers

INTERNATIONAL CLASS NO.	1300/11580
SPECIFICATION	Z/1300
SCREW TYPE	A	B	C	D
INJECTION UNIT
screw diameter mm	110	120	130	140
screw L/D ratio L/D	25.1	23	21.2	19.7
shot volume (theoretical) cm3	5559	6616	7765	9006
injection weight(PS) g	5059	6021	7066	8195
injection rate g/s	752	895	1050	1218
injection pressure mpa	208	175	149	128
screw speed rpm	90
CLAMPING UNIT
clamping force kn	13000
space between tie-bars (w*h) mm	1380*1280
max.mould height mm	1400
min. mould height mm	600
ejector stroke mm	360
ejector force kn	248
max.daylight mm	2900
mould opening stroke mm	2300/1500
max.mold weight t	23
OTHERS
pump max. pressure mpa	21/16
pump motor power (servo) kw	55+55+7.5
heating power kw	86
numbers of heating area segment	6+1
machine dimension (l*w*h) m	11.7*3.55*4.2
oiltank cubage l	1600
machine weight ton	65

Company Information
HAILONG GROUP-NINGBO BEILUN ALLWAY MACHINERY CO., LTD.is located in HAILONG industrial park, national developement zone beilun ningbo ,our company is long engaged in the professional manufacture of high precision injection molding machine. we have successively introduced machines with clamping force form 90-3000Ttons as well as more than 20types of special application machines which is leading the market.
Our company has a high qualified team who are specialized in the research and development as well as manufacturing engineering technology for all kinds of injection molding machine for long time. we have created lots of injection molding machneproduct proprietary technology and we have built up quick respinse output mechanism that can offer personalized solutions for our customer based on their requirements. with strong and powerful strength for the technology design and equipment manufacture , our products design has integrated with international advanced technology as well as the indeas of keeping on improving , creation and transcendence.
Based on the powerful strength of the head company HAILONG GROUP ,our company has built a HAILONG machinery intelligent manufacture system.integrated with european technology "WELLISH&"AOTAI" brand several series of export-oriented high end special application injection molding machine are very popular with customers form home and abroad.
Exhibition Show
ALLWAY---ALWAYS ON THE WAY WITH YOU !

---
