| Model | 3WFQ-1000A |
| Overall size | 3470x1250x1450 mm |
| Tank capacity | 1000 L |
| Tractor power | ＞30HP |
| Work height | ＞7 m |
| Work width | ＞16 m |
| Sprayer pump | 6 cylinder Diaphragm pump |
| Flow | 15-60 L |
| Fan diameter | 800 mm |
| Tyre | Vacuum width tyre |
| drive shaft speed | 540r/min |
| Spray control type | Sectional Control/Independent Switch |
| Sprayer nozzle | 10-14 Pcs |
| Liquid mixing type | Reflux stirring/jet stirring |
| Work effect | 0.5 ha |
| Filter unit | Two-stage filtration |
| Model | 3WFQ-1600 |
| Overall size | 3470x1250x1450 mm |
| Tank capacity | 1600 L |
| Tractor power | ＞40 HP |
| Work height | ＞7 m |
| Work width | ＞16 m |
| Sprayer pump | 6 cylinder Diaphragm pump |
| Flow | 15-70 L |
| Fan diameter | 800 mm |
| Tyre | Vacuum width tyre |
| drive shaft speed | 540r/min |
| Spray control type | Sectional Control/Independent Switch |
| Sprayer nozzle | 10-14 Pcs |
| Liquid mixing type | Reflux stirring/jet stirring |
| Work effect | 0.5 ha |
| Filter unit | Two-stage filtration |
| Model | 3WFQ-2000 |
| Overall size | 3670x1350x1550 mm |
| Tank capacity | 2000 L |
| Tractor power | ＞60 HP |
| Work height | ＞7 m |
| Work width | ＞16 m |
| Sprayer pump | 6 cylinder Diaphragm pump |
| Flow | 15-70 L |
| Fan diameter | 800 mm |
| Tyre | Vacuum width tyre |
| drive shaft speed | 540r/min |
| Spray control type | Sectional Control/Independent Switch |
| Sprayer nozzle | 10-14 Pcs |
| Liquid mixing type | Reflux stirring/jet stirring |
| Work effect | 0.5 ha |
| Filter unit | Two-stage filtration |
