59/72/75 Teeth Laminated Gear Clutch Facing for Engineering Machinery

Product Description

TL3000, Non Asbestos Gear Teeth Facing For Industrial Brake/ Clutch System, is a Non Asbestos Woven Laminated Sheet with exceedingly high hardness and strength. The material is woven from Kevlar and other synthetic fabric yarns containing brass wire. After being impregnated with special resin and pressed into rigid flat sheet, the material shows outstandingly good resistance to wear and compression and excellent stability.
TL3000 is a heavy duty material extensively used in oil drilling and wind power industry. It can be installed in industrial brake and clutch system, power transmission system and electric magnetic brake engine.

Dimension: Length x Width:762mm x 762mm (30 inches x 30 inches) Thickness:3.2mm-12.7mm ( 1/8 - 1/2 inch) Frictional Properties: Normal 0.48 Hot 0.42 Static, 200°F 0.50 Static, 400°F 0.48 Recommended Operating Range: Max. Pressure, psi 250 Max. Rubbing Speed, ft/min 5000 Max. Intermittent Temperature 600°F (315°C) Max. Continuous Temperature 550°F (287°C)

---
