| US$9,000.00-11,000.00 | 1 Piece (MOQ) |
| Model | Unit | XL6340 Servo |
| Table size | mm | 1600×400 |
| Table travel (X/Y/Z) | mm | 1250/450/650 |
| Table loading capacity | kg | 800 |
| Table feed. (X/Y/Z) | mm/min | 25~800/25~800/8-267 |
| Table swivel angle | ±50° | |
| Spindle taper | 7:24 ISO50 (H) 7:24 ISO40 (V) | |
| Stroke of spindle quill | mm | 127 (V) |
| Distance between spindle nose and table | mm | 200-850 |
| Distance between horizontal spindle and table | mm | 0-500 |
| Distance between horizontal spindle and arm | mm | 200 |
| Spindle speed range | r.p.m | 12 steps 60-1850 (H) 16 steps 66~4540 (V) |
| T-slots(NO./width/pitch) | mm | 3/18/100 |
| Arm travel | mm | 700 |
| Main motor power | Kw | 5.5 (H) 3.7 (V) |
| Torque of X/Y/Z axis AC servo motor | N.m | 10 |
| Overall size | mm | 2520×2100×2500 |
| Net weight | kg | 3250 |
| X Y Z axis servo motor |
| Worktable swivel ±50° |
| Drill chuck |
| Collet chuck kits |
| Reduction sleeve |
| Draw bar |
| Mill arbors |
| Working lamp |
| Coolant system |
| Lubricating |
| Chip tray |
| Tools and box |
| Air draw bar |
| 58 pcs Clamping kits |
| Spindle protection |
| Machine vice 160mm |
| XYZ axis Digital readout(DRO) |
| Rotary table HV-12 |
| Universal dividing head F11-160A |
| Variable spindle speed |
