| US$6,640.00-6,785.00 | 100 Pieces (MOQ) |
| TECHNICAL SPECIFICATIONS | ||||||||||
| ITEM | KLS-3000 | |||||||||
| Laser power | 3000W | |||||||||
| Working mode | Continuous fiber | |||||||||
| The laser wave length | 1070nm+10 | |||||||||
| Fiber length | The standard 10m length supports 15m | |||||||||
| Welding speed range | 0-120 - mm/s | |||||||||
| Weldingthickness range | 0.5-10mm | |||||||||
| Weld requirements | 0.2 mm or less | |||||||||
| The welding head | Single swing/double swing | |||||||||
| Suitable material | Aluminum, carbon steel, stainless steel, galvanized sheet, etc | |||||||||
| voltage(V) | 380V | |||||||||
| Cooling way | Water cooled | |||||||||
| Collimating focal length | 150mm | |||||||||
| Output fiber terminal | QBH | |||||||||
| Ambient temperature | Temperature 0-60ºC; humidity10-90% | |||||||||
| Machine size | 100cm*52.5cm*74cm | |||||||||
| G.W | 260KGS | |||||||||
