Factory Selling Professional CA20 Power Amplifier High Power 2 Channel 1350W 8 ohm Analog Audio Amplifier
| Model | PA4 | PA6 | PA8 | PA10 | PA12 | customized |
| Channel number | 2 | 2 | 2 | 2 | 2 | 2 |
| Rated output power | Stereo power 8Ω | 400W | 600W | 800W | 1000W | 1200W | 400W-1200W |
| Stereo power 4Ω | 600W | 900W | 1200W | 1500W | 1800W | 600W-1800W |
| Rated bridged output power 8Ω | 1200W | 1800W | 2400W | 3000W | 3600W | 1200W-3600W |
| Power supply | AC 220-240V 50Hz/60Hz (100V-125V can be customized) |
| Total harmony distoration(THD) | <0.025% |
| Frequency response | 20Hz-20KHz,±0.5dB |
| Signal to noise | >112dB |
| Slew rate | >100V/us |
| Damping factor | >1500:1 |
| IMD | <0.05% |
| Input sensitivity(*40/32dB) | 0.775V/1.4V(32dB) |
| Input impedance | 20k ohms balance/10k ohms unbalance |
| Input CMRR | >80dB |
| Crosstalk | >80dB |
| Input link | One balance XLR interface per channel |
| Output link | One 4-POLESpeakon interface per channel and a pair of plum blossom anti-touch binding posts |
| Protection | Full-featured protection circuit, including temperature (overheating), short circuit, DC, voltage limit, overload, overcurrent, distortion limiter, undervoltage/overvoltage, on/off noise, load mismatch (low resistance), soft-start on boot, Power-on anti-surge, radio interference, secondary wave, high-frequency output automatic detection (UHF) protection and other protections |
| LED indicator | Protection (PEA), Signal (SIG), Overheating (TEM), Bridge (BRI), Stereo (STE), Mono (PAR) |
| Cooling system | By the air convection mechanism from the front to the rear, the internal air is forced to dissipate heat, and the automatic continuously variable speed dual fans are forced to cool |
| Output circuit type | Class H |
| Voltage gain 0.775V/0dB | *75 | *92 | *106 | *120 | *135 | customized |
| Max power consumption | 1000VA/4.3A | 1500VA/6.5A | 2000VA/8.7A | 2500VA/10.9A | 3500VA/15.2A | customized |
| Weight | 13.5Kg | 16.3Kg | 16.8Kg | 17.5Kg | 25Kg | customized |
| Dimensions(L*D*H) | 480*365*88mm | 480*465*88mm |
| Remark:Above standard parameters are just for your reference,we can design by your requirements. |
| Model | PA4 | PA6 | PA8 | PA10 | Customized |
| Channel number | 4 | 4 | 4 | 4 | 4 |
| Rated output power | Stereo power 8Ω | 400W | 600W | 800W | 1000W | 400W-1000W |
| Stereo power 4Ω | 600W | 900W | 1200W | 1500W | 600W-1500W |
| Rated bridged output power 8Ω | 1200W | 1800W | 2400W | 3000W | 1200W-3000W |
| Power supply | AC 220-240V 50Hz/60Hz (100V-125V can be customized) |
| Total harmony distoration(THD) | <0.025% |
| Frequency response | 20Hz-20KHz,±0.5dB |
| Signal to noise | >112dB |
| Slew rate | >100V/us |
| Damping factor | >1500:1 |
| IMD | <0.05% |
| Input sensitivity(*40/32dB) | 0.775V/1.4V(32dB) |
| Input impedance | 20k ohms balance/10k ohms unbalance |
| Input CMRR | >80dB |
| Crosstalk | >80dB |
| Input link | One balance XLR interface per channel |
| Output link | One 4-POLESpeakon interface per channel and a pair of plum blossom anti-touch binding posts |
| Protection | Full-featured protection circuit, including temperature (overheating), short circuit, DC, voltage limit, overload, overcurrent, distortion limiter, undervoltage/overvoltage, on/off noise, load mismatch (low resistance), soft-start on boot, Power-on anti-surge, radio interference, secondary wave, high-frequency output automatic detection (UHF) protection and other protections |
| LED indicator | Protection (PEA), Signal (SIG), Overheating (TEM), Bridge (BRI), Stereo (STE), Mono (PAR) |
| Cooling system | By the air convection mechanism from the front to the rear, the internal air is forced to dissipate heat, and the automatic continuously variable speed dual fans are forced to cool |
| Output circuit type | Class H |
| Voltage gain 0.775V/0dB | *90 | *100 | *120 | *130 | Customized |
| Max power consumption | 1700VA/7.6A | 2300VA/10.2A | 2700VA/12.6A | 2960VA/14.3A | Customized |
| Weight | 16Kg | 18Kg | 24Kg | 26Kg | Customized |
| Dimensions(L*D*H) | 480*465*88mm |
| Remark:Above standard parameters are just for your reference,we can design by your requirements. |
1. With high Slew Rate, strong ability to restore the details to get more clear and delicate high-frequency performance.2. With high Damping Factor, strong low-frequency control force to make a strong low-frequency straight extension.3. The high value of signal to noise ratio, to make sure get a better sound with high fidelity.4. The new circuit design, adopts the SMT surface mount technology, to improve the consistency and efficiency of the machine.5. Class AB circuit design, advanced power supply technology to reduce the overall power consumption by 40%, reducing the system heating and the weight of the product.6. Suitable for: KTV, stage performance,conference room, multi-function hall, bar ,theatrer and church etc.
Welcome to contact us if interested.
