| Model | Alp9350Skcst | ||||
| Dimension(Optional) | Axle No. | Rated Load (Kg) | Tire No. | Tire Size | |
| 20ft | 2 | 40000 | 8 | 825R20 1000R20 1100R20 1200R20 12R22.5 | |
| 40ft 45ft 48ft 53ft | 3 | 60000 | 12 | ||
| 40ft 45ft 48ft 53ft | 4 | 75000 | 16 | ||
| Manufacture | Qingdao Eleph Industry & Trade Co., Ltd | ||||
| Wheel Base (Mm) | 1310 | ||||
| Leaf-Spring Pcs | 10 | ||||
| Axle | 13/16/18 T | ||||
| Suspension | Heavy Duty Mechanic Suspension With Leaf Springs | ||||
| Main Beam Material | Q345B Manganese Plates, Automatic Submerged Arc Welded | ||||
| Brake System | Dual Line Braking System With Automatic Braking System/Chambers | ||||
| Brake Air Chamber | Double Model | ||||
| Kingpin | 2' Or 3.5' Interchangeable | ||||
| Landing Gear | 28T Loading Capacity With 80T Static Lifting Capacity. | ||||
| Platform | Skeletal Chassis Loading Deck | ||||
| Brake System | Dual Lines Braking System With Automatic Air Chambers | ||||
| Brake Air Chamber | Four Double And Two Single Chamber | ||||
| Electrical System | 24V, 7core Socket, Lights According To European Standards. | ||||
| Mainbeam Size | Upper Plate | 14mm | |||
| Lower Plate | 16mm | ||||
| Mid Web | 8 Mm | ||||
| Height | 500-520mm | ||||
| Tool Box | 1 Box Of Standard Tools | ||||
| Spare Tire Carrier | 2 Sets | ||||
| Color And Logo | Depends On The Buyer's Requirement. | ||||
| Pin Height | According To The Height Of The Tractor Saddle. | ||||
| Painting | Three Coats Painting; Any Color Will Be Available | ||||
| Other Specifications | The Frame Can Be Flat Plate Style And Skeleton Style.Twist Lock Settings Installed 12 Pics, 8 Pics, And 4pcs To Satisfy The Containers With Different Sizes For Convince. | ||||
| Application | For 2x20ft Or 1x40ft Containers Transport | ||||
