PA PVC PE Single Wall Corrugated Pipe Production Line

Product Description

PA PVC PE Single Wall Corrugated Pipe Production Line
Introduction
Usually for corrugated tube/ pipe with sizes 4.5-8mm, we will advise you with our sj-30/30
Extruder;
For corrugated tube/ pipe with sizes 9-32mm, we will advise you with SJ-50/30 extruder;
For corrugated tube/pipe with sizes 16-63mm, we will advise you with SJ-65/30 extruder;
For bigger sizes, we have extruders SJ-90/30, SJ-120/30, etc
L/D for PP, PE=30: 1, for PVC=28: 1, for PA=25: 1
Specification of PP, PE, PVC, PA single wall corrugated pipe extrusion lines,

Pipe diameter	4.5-8	8-32	16-63
Motor power	4	11	18.5
Extruder	sj-30/30	sj-45/30	sj-65/30
Extruding capacity (kg/h)	10	30-40	60-80
Mould pairs	50	50	50
Cooling	water&air	water & air	water &air

WHY CHOOSE WEIER?
(1)We are engaged in macromolecule science, is the director member of WPC (plastic & wood
Production council of Chinese plastic community)
(2)We cooperated with many domestic universities to develop special plastic machines to meet
Domestic and foreign customer's requirement.
(3)We become the test and industrialization centre of plastic engineering technology research
institute Of Qingdao Science and Technology University.
(4) we bring in and absorb advanced processing engineering of foreign plastic machines to realize
Chain service of technics and machines.
(5) We have experiences in this field since 1980s
(6) We have our production bases for WPC and plastic product in China with large scales, which
Shows our machine's production power
(7) We have strong technical teams and cooperate with China scientific institution to develop,
Improve and test our machine, to ensure what customers get are the most reliable machines from
China.
(8) We select the most reliable mechanical and electrical parts for our machine with all famous
reliable Brands, with European CE certificated.
(9) We put our heart into every business with aim of long term cooperation.
(10) We have perfect service system-- Our president is devoting himself to pre-sale, on-sale and
after-sale Service. WEIER JUST DO WIN-WIN BUSINESS! ! !

---
