Heavy Duty UPS-20j Mining Shotcrete Machine for Underground Works

Product Description

Product Description
The UPS-20J mining shotcrete truck is a special equipment developed and upgraded based on the initial concrete shotcreting technology and construction conditions of domestic mines. It boasts a maximum shotcreting volume of 20m³/h and is widely utilized in wet shotcreting operations for supporting concrete in underground mines or small and medium-sized underground works. The equipment is characterized by large shotcreting volume, pipe blockage proof, low rebound, stable and reliable performance, among other features.
It features a diesel and electric dual system, electric construction, diesel emergency response, ensuring continuous construction progress.
Operated via wireless remote control, enabling precise control over the mechanical arm operation, resulting in fast, efficient, safe, and energy-saving performance.
Equipped with a 400L accelerator tank to meet the construction volume requirements for large sections.
The equipment has a small turning radius, making it convenient for entering and exiting small spaces.
The maximum shotcreting volume reaches 20m ³/h, showcasing high shotcretingefficiency and pipe blockage proof.
Optimized and upgraded structure of the entire machine, featuring low failure rate, high universality of accessories and consumables and low operation cost.
Product Parameters

Max mumoveralldimension(L×W×H)	7830×2000×2520mm
Self-weight	12.5t
Operatingmode	Electric system + diesel engine emergency response system
Operatingrange(W×H)	15×8.5m
Maximumshotcretingvolume	20m³/h
Controlmode	The boom adopts wireless remote control
Chassis model	Self-made engineering vehicle chassis
Power	110kW
Wheelbase	3540mm
Maximum travel speed	17km/h
Maximum gradeability	25°
Minimum outer turning radius	6301mm
Minimum inside turning radius	3768 mm
Minimum ground clearance	408mm
Structural form of boom	Three-section arm two-stage telescopic
Maximum spray height	8.5m
Maximum spray width	2×7.5m
Boom pitch angle	-30°~+50°
Boom slewing angle	0~270°
Axial rotation of spray nozzle seat	360°
Axial swing of spray nozzle seat	240°
Deflection angle brushing of spray nozzle	8° ×360° continuous
Total motor power	45kW
Number of cylinders	2
Cylinder (cylinder diameter X stroke)	90mm×800mm
Concrete cylinder (cylinder diameter × stroke)	160mm×800mm
Pumping line	125-80 reducer pipe
Maximum size of sprayed aggregate	25mm
Maximum pumping volume	20m³/h
Hopper capacity	0.35m³
Material receiving height	1310mm
Air compressor displacement	10.5m³/min,45kW
Working pressure of air compressor	0.7MPa
Admixture system displacement	620L/h
Admixture system pressure	1MPa
Volume of accelerator tank	400L

Detailed Photos
FAQ
1,What can you buy from us?
Our current main products include comprehensive solutions for underground engineering machinery and intelligent mining equipment. This includes tunnel boring machines, integrated arch anchoring and spraying trolleys, arch anchoring trolleys, integrated arch drilling trolleys, arch frame installation trolleys, wet spraying rigs, and rock drilling rigs. We have the capacity to provide customers with integrated total solution services.
2,What about the MOQ?
The Minimum Order Quantity (MOQ) is 1 set.
3,What payment terms do you accept?
We accept T/T with a 50% prepayment.
4,What about the order lead time?
The usual lead time is 15 days.
5,What logistics methods can you use for shipment?
Truck delivery can be arranged in Central Asia and Russia, and you can also choose rail and sea shipping.
6,How is your delivery time?
The delivery time via China-Europe trains is 15 to 20 days, while sea shipping takes approximately 2 to 3 months.
7,How about your customer service and after-sales service?
We offer 24/7 online support and provide after-sales support in Russia and Central Asia.

---
