Mj3928X400 Horizontal Band Saw Machine for Woodworking Wood Bandsaw Resaw

Product Description

MJ3928X400 Horizontal Band Saw Machine for Woodworking
Technical Specification:

Model	HHG400B
Max. Cutting Width	400mm
Max Cutting Thickness	450mm
Saw elctrical up and down	350mm
Main Saw motor	15kw
Saw Wheel Diameter	730mm(wheel with glue tape)
Saw blade width	40mm
Main Spindle diameter	50mm
Overall dimensions	2300× 2400× 2200mm

.Performance and advantage1. High efficiency:Hydraulic feeding, the opening speed can generally reach 18 meters/minute.2.Low consumption:1) Save wages:recruit ordinary workers to solve the difficulty of recruiting masters andreduce wage costs.2) Save material: The sawing path is small, and the board surface is smooth. Compared withthe traditional vertical saw,each board can save 4-5mm sawing path and materials,andthe planing process can be eliminated. It Can be sanded directly or after drying.3. Intelligent:The intelligent positioning of the worm gearreducer is more accurate and reduces the opening error. Product Details:


Worktable:
The worktable is made of 10MM thick plate fully welded, and then covered with root plates at the bottom, and then completed by milling process.


Powerful feeding Motor:
The feeding table is driven by a hydraulic motor to drive the bearing to drive the specially designed feeding wheel to rotate and feed. The return table is driven by a hydraulic motor to drive the bearing to drive the specially designed return wheel to rotate and feed the material.
Control Panel:
Easy to operate and with emergency stop button,guarantee safely work.
Cinta transportadora auxiliar
MORE PHOTOS:
Related Products:
https://zhongdingmachinery.en.made-in-china.com/product/gvhQYVxUuEAC/China-Zd400t-Wood-Cutting-Machine-3200mm-Sliding-Table-Panel-Saw-Machine.html
https://zhongdingmachinery.en.made-in-china.com/product/tKixkedOHnfU/China-Zd450c-Furniture-Woodworking-Furniture-Kdt-Edge-Banding-Machine-Edge-Bander.html
https://zhongdingmachinery.en.made-in-china.com/product/wdWayCVYllAD/China-Sp-R-RP1000-Planing-Wood-Sanding-Machine-with-Planner-Wide-Belt-Sander-with-Planning-Machine.html
Certificate:
Our company:
Qingdao Zhongding Machinery Co., Ltd is professional at manufacturing woodworking machines. Our main products includes: sliding table saw(panel saw), edge banding machine, hydraulic cold press, hot press, carpenter drilling machine ( boring machine), etc. We are factory, we provide the machine with reasonable price and high quality, and welcome to visit our factory and our products.

---
