Jwell Mini Automatic Blow Molding Machine for Jerrry Can, Plastic Bucket, Palstic Barrels, 15-30L Plastic Jerrycans and Chemical Packaging Bottles

Product Description

Product Parameters

Model	Unit	BM30DN-C
Max product volume	L	30
Dry cycle	Pc/h	450*2
Die head structure	type	Continuous type
Main screw diameter	mm	100
Max plasticizing capacity(PE)	kg/h	190
Driving motor	KW	55
Oil pump motor power(Servo)	KW	22
Clamping force	KN	300
Space between platen	mm	380-860
Platen size W*H	mm	580*600
Heating power of die head	KW	20
Machine dimension L*W*H	m	5.6*4.8*4.5
Machine weight	T	18
Total power	Kw	125

Detailed Photos

Product Description
Product Description:
The JWZ-BM30DN-C Blow Molding Machine is engineered to produce 15-30L plastic jerrycans and chemical packaging bottles with unmatched efficiency and precision. This machine is a perfect choice for industries requiring reliable, high-quality packaging solutions.
Key Features:
Versatile Production Capabilities: Designed for producing 15-30L plastic jerrycans, ideal for storing industrial chemicals, lubricants, and other liquids. Continuous Type Die Head with Up-Blowing Structure: Ensures seamless production with integrated auto-deflashing, on-line scrap conveying, leak testing, and packing functions, significantly reducing labor costs and boosting productivity. Toggle-Type Platen Structure: Offers uniform clamping force, enhanced durability, and easy mold assembly and disassembly, ideal for accommodating large molds. Optional Multi-Layer Co-Extrusion: Produces multi-layered bottles or jerrycans for improved strength, barrier properties, and chemical resistance. Optional View Strip Line System: Enables clear visibility of liquid levels in finished products, enhancing user convenience. Optional Hydraulic Servo Control System: Provides precise operation, energy efficiency, and improved machine stability. Applications:
Chemical packaging bottles for hazardous materials, cleaning agents, and industrial liquids. Plastic jerrycans for oil, fuel, and lubricant storage. Agricultural and industrial liquid containers for fertilizers, pesticides, and solvents. This advanced blow molding solution by JWELL is designed to meet the growing demands for plastic bottles and jerrycans, ensuring durability, cost-efficiency, and exceptional product quality for the chemical and industrial packaging industries.
