| US$3,000.00-3,300.00 | 1 set (MOQ) |
| Items | Specifications | |
| Vessel capacity (L) | 50 | |
| Vessel jacket capacity (L) | about 16.0 | |
| Heating transfer area of condenser(m²) | about 0.43 | |
| Feeding funnel capacity(ml) | 2000 | |
| Lid cover | stirrer port | 50# flange |
| temp. sensor port | 35# flange | |
| condenser port | 50# ball-ground port | |
| Liquid feeding port | 34# standard ground port | |
| Feeding funnel port | 40# standard ground port | |
| Solid feeding port | 80# flange | |
| Glassware material | borosilicate 3.3 | |
| Frame | SUS304 | |
| Working temp. range (ºC) | -80~250 | |
| Pressure range(mPa) | -0.1~0.0 | |
| Jacket pressure tolerance(mPa) | ≤+0.03 | |
| Motor power(W) | 140 | |
| Speed adjustment | frequency control | |
| Speed range(rpm) | 50~400 | |
| Temp. sensor type | PT100 | |
| Temp. accuracy(ºC) | ±0.1 | |
| Thermo insulation hose connector | 1/2 male screw | |
| Seal material | PTFE | |
| Drain port height(mm) | about 450 | |
| Stirrer type | Paddle, SUS304 with PTFE coated | |
| Power supply | 110-240V~,50/60Hz | |
| Operating temp. (ºC) | 5~35 | |
| Ambient humidity (%) | ≤ 65 | |
| Machine size (mm) | 900W×690D×2100H | |
| N.W.(kg) | 82 | |
