Push Pull Force Horizontal Directional Drilling Xz320 Xz320e Xz320d Xz360e

Product Description

ABOUT US:
As a leading Chinese machinery and truck exporter, we have a professional experience of 8years in this field. Besides our trucks of high quality, our international sales team will also provide you excellent logistics service and after-sales service. We will always do our best to solve all the problems and put our customer's interests in the first place.
We can supply:
1) ALL kinds of trucks.
(Dump truck, mining dump truck, tractor truck, truck trailer ,towing truck , water tank truck, concrete mixer truck, oil tank truck, garbage truck, cargo truck, port terminal tractor, refrigerated truck, truck mounted crane, fire truck, suction sewage truck, bus , etc)
2) All kinds of construction machinery.
(Wheel loader, excavator, folklift, cranes, paver, road roller etc.)
Push/Pull Force Horizontal Directional Drilling XZ320 • Strong Power:
it adopts178kW diesel engine with turbocharged torque increment function which ensures that the machine can perform pipe laying work at any complex geological conditions.
• Dual speed power head:
drilling and pulling at low speed ensure smooth operation; The power head can slide at faster speed to reduce the auxiliary time and improve work efficiency during the assembly/disassembly of drilling stem with empty load.
• Steel track:
mounted with steel track, it is applicable to muddy work conditions.
• Float clamp:
the patented float clamp can effectively extend the service life of the drill stem.
• Rotatable control panel:
it widens the field of view and reduces operator fatigue, which makes it more simple and comfortable to operate the machine.
• Simple to operate:
the rotation and push/pull of the power head is controlled separately, and it's simple and convenient to operate. The operator can master the operation skills through short-time training.
• Convenient maintenance:
the engine hood is reasonably designed, which is convenient for engine maintenance and filter element replacement.

Items Unit Parameters Engine Make Dongfeng Model 6CTA8.3-C240 Rated power kW/ rpm 179/2200 Push/pull force Type 2-motor rack type Max. pull/push force kN 400/400 Power head rotary speed m/min 0~22 Slewing Type Motor drive gear transmission Max. torque of power head N.m 14000 Power head rotary speed r/min 0~100 Drill stem Type Standard API drill stem Diameter mm φ83 Length (single) m 3 Drill mounting Type Box type Adjustment angle ° 10~22 Travel drive Type Self-propelled steel track Travel speed km/h 2.8 Slurry pump Type Hydraulic drive Flow L/min 450 Dimension mm 7000x2170x2450 Weight t 12

---
