Xt-X-18 Type Surgical Microscope Is Suitable for Orthopedics, Spine Surgery, Plastic Surgery, Hand Surgery and Other Microsurgical Operations.

Product Description

Product Features
Adopt four-channel optical continuous variable magnification and observation system, with clear imaging, wide field of view and strong body vision
Adopt electronic touch screen or handle control operation
It has electromagnetic lock and locking function
The instrument has three large objective lenses with different focal lengths, which can be applied to surgical needs of various depths
Illumination adopts cold light source coaxial internal lighting system, equipped with two groups of light sources, fast switching
The instrument has electric fine-tuning focus function
The instrument is equipped with X-Y plane mover
Double binocular, face-to-face 180 operation
Equipped with universal adjustable binocular assistant mirror
Technical parameters
Binocular assistant lens and main lens with same magnification
Lighting field of view: using 15V/150W German OSRAM halogen bulb, equipped with two sets of light sources, can be quickly switched.
Lighting form: coaxial lighting of light guide fiber.
Control mode: stepless dimming.
Lighting brightness: ≥ 50000Lx
Moving range of electric X/Y plane mover: ≥ 40mm with one-key reset function
Power supply: 220V 10% 50Hz

Eyepiece magnification	12.5X Elver wide-angle eyepiece
Working distance	200mm,250mm,300mm
Total magnification	5X ~ 25X, electric or manual continuous magnification
Field of view range	55mm ~ 75mm
Visual adjustment range	± 6D pupil
Distance adjustment range	55mm ~ 75mm
Main auxiliary lens eyepiece observation angle	45

---
