Cheap 5 Axis Vertical Machining Center Vmc550 CNC Milling Machine

Product Description

Cheap 5 axis Vertical Machining Center VMC550 CNC milling machine
Main features:
X/Y/Z-axis adopts Taiwan HIWIN linear guide ways( width 45mm )
X/Y/Z-axis servo motor connects Taiwan HIWIN high precision ball screws Taiwan brand drum-type tool magazine
Bed body, worktable, slide, column, headstock, etc are made up by high rigidity cast iron material,
Taiwan Posa brand spindle unit with 8000rpm,the max.spindle speed can be achieved to 6000rpm.with high precision,high rigidty.NSK bearing
Taiwan brand CHENSOUND umbrella type tool magazine
Equipped with large flow cooling pump and large capacity water tank
Electromagnetic valve group by PLC program control, ensure that the spindle loose tools, spindle center blowing, spindle folder tools, air cooling spindle etc
The guideway and ballscrew pair adopt centralized automatic lubrication, Each node is equipped with a quantitative oil separator.

Specifications	Units	XH7132(VMC550)	XK7132
Table travel (X,Y,Z)	mm	550x320x500	550x320x500
Table size	mm	920×320	920×320
Number/Width/Distance of T-slot	mm	3-14-100	3-14-100
Distance from spindle nose to table surface	mm	100-580	100-580
Distance sfrom spindle axis to column guideway	mm	370	370
Taper of spindle	\	BT40	BT40
Spindle speed range	rpm	60-8000	60-8000
Spindle motor power	KW	Servo 3.7	Servo 3.7
Rapid feed speed	mm/min	24000	24000
Feed speed	mm/min	10000	10000
Tool magazine capability	qty	12
Max.dimension of tool	mm	120×200
Max.weight of tool	kg	8
Positioning accuracy	mm	±0.02	±0.02
Repeat positioning accuracy	mm	0.01	0.01
Overall dimension	mm	2250x2000x2200	2100×1970×2170

,

No.	Name	Specification	Qty	Remark
1	Machine		1
2	spanner	5,6	Each 1
3	wrench	S22-24	1
4	Adjusting screw and Sizing block		6 set
5	Operating manual		1	Mechanical part
6	Operating manual		1	Electrical part
7	Accuracy test list		1
8	Packing list		1

Standard equipments:
GSKCNC system
RS232 interface
Taiwan 12 umbrella tool station,
Taiwan BT40 8000rpm spindle unit,
3-Axis tursite box guideway,
Taiwan Hiwin leadscrew,
Japan NSK bearing,
Full-cover protection,
Worklight,
Coolant system,
Auto-lubrication,
Electrical handwheel

Optional accessories:
the 4th axis
FANUC 0i mate-MD
SIEMENS 828D

---
