Small Multi-function Micro Tillage Machine//power tiller//mini tiller

Product Description

Product Description
Small Multi-function Micro Tillage Machine//power tiller//mini tiller
Product Description
Mini Tiller// farm ditcher// weed removal machine
Characteristic:
This mini tractor has the characteristic of compact structure and light weight, can be completed to do farm works of rotary tillage, weeding, deep ploughing, ridging, ditching, sowing, fertilizing, spraying chamicals etc. equipped with reference supporting facilities.
Usage:
Rotary tillage, ditching, earthing .It's widly used for film house, vegetable plot, hill and terrace.

Technical Data
Assembled with rotary cultivator set		Overall Dimension (mm)			1480*805*965
		Structural weight (kg)			113
		Transmission mode			Vee Belt
		Clutch			Tensioner Pully
		Tilling width (mm)			920
		Tilling depth (mm)			200~250
		Working speed (m/s)			≥0.2
		Productivith (hm²/h·m)			0.08-0.12
		Fuel consumption (kg/hm²)			≤12
		Max dia.(mm)			185
		Total pcs of knives			24
		Rotary cultivator set No.			DGX
Engine		ModeL No.			F186S
		Rated Power (KW/HP)			6.3/8.6
		Rated Speed (r/min)			1800
		Bore x Stroke(mm)			86*72
		Fuel tank capacity (L)			5.5
		Engine type			Single Cylinder, Vertical 4 stroke, Air-cooled, Direct Injection Type
		Starting			Recoil start

Product show:
