Basic Info.
Max.Capacity
50-100 L/min
Driving Type
Diesel Engine
Structure
Single-stage Pump
Type
Positive-Displacement Pump
Application
Clarified Water Pump, Sewage Pump, Slurry Pump, Pump Water in Agriculture
Diesel High Pressrue Water Pump
1.5" 2" 3"
Water Pump
Dp15, Dp20 Dp30
Diesel Water Pump
Sp20, Sp30, Sp40
Transport Package
by carton
Specification
1.5" HIGH PRESSURE DIESEL WATER PUMP
Production Capacity
3000pcs/month
Product Description
| Model : | DP20H-C | DP30H-C | DP40H-C |
| SUCTION,DISCHARGE PORT DIAMETER[mm(in)] | 50(2 in) | 80(3 in) | 100(4 in) |
| MAX CAPACITY(m3/h) | 30 | 47 | 90 |
| TOTAL HEAD LIF(M) | 80 | 80 | 60 |
| MAX SUCTION HEAD[m(ft)] | 8(26.25) | 8(26.25) | 8(26.25) |
| ROTATION SPEED(rpm) | 3600 | 3600 | 3600 |
| SELF-PRIMING TIME(s/4m) | 30 | 30 |
|
| OVERALL DIMENSION(LxWxH)(MM) | 565x440x550 | 650X475X605 | 690X550X690 |
| DRY WEIGHT[kg(lbs)] | 58(127.6) | 78(171.6) | 82(180.4) |
| ENGINE MODEL | SR178F | SR186F | SR188F |
| RATED POWER[KW(Hp)] | 3.7(5.03) | 6(9) | 6.3(10) |
| RATED ROTATION SPEED(rpm) | 3600 | 3600 | 3600 |
| DISPLACEMENT[ml(cu.in)] | 296(18.06) | 406(24.77) | 456(27.82) |
| FUEL TANK CAPACITY[L(gal.)] | 3.6(0.792) | 5.5(1.21) | 5.5(1.21) |
CAST IRON HIGH PRESSURE WATER PUMP
High quality normal clean aluminum water pump 2" 3" 4",aluminum high pressure water pump 1.5" 2" 3",cast iron high pressure water pump 2" 3"4".welcome your enquiry !
Recoil start or key start with battery 1.5" high pressure fire water pump, use for fire fighting.
Model No: Dp15
Suction discharge port diameter(mm) 1.5"
Cont head (m) 60m
Self-priming time (s/4m) 30
Max suction head (m) 8
Cont capacity(m3/hr) 8
Engine model 178f
Speed (rpm) 3000
Type single-cylinder vertical 4-stroke air cooled diesel engine
ALUMINUN HIGH PRESSURE WATER PUMP
| Model : | DP15H1 | DP15H2 | DP20H | DP30H |
| SUCTION,DISCHARGE PORT DIAMETER[mm(in)] | 40(1.5in) | 40(1.5 in) | 50(2 in) | 80(3 in) |
| MAX CAPACITY(m3/h) | 20 | 22 | 30 | 40 |
| TOTAL HEAD LIFT[m(ft)] | 42(196.848) | 55(180.444) | 65(213.252) | 70(229.656) |
| MAX SUCTION HEAD[m(ft)] | 8(26.25) | 8(26.25) | 8(26.25) | 8(26.25) |
| ROTATION SPEED(rpm) | 3600 | 3600 | 3600 | 3600 |
| SELF-PRIMING TIME(s/4m) | 30 | 30 | 30 | 30 |
| OVERALL DIMENSION(LxWxH)[mm(in)] | 565x440x550(22.24x17.31x21.65 | 565x440x550(22.24x17.31x21.65 | 570x455x570(22.44x17.9x22.44) | 570x455x570(22.44x17.9x22.44) |
| DRY WEIGHT[kg(lbs)] | 46(101.2) | 47(103.4) | 52(114.4) | 69(151.8) |
| ENGINE MODEL | SR178 | SR178F | SR178F | SR186F |
| RATED POWER[KW(Hp)] | 3.7(5.03) | 3.7(5.03) | 3.7(5.03) | 6(9) |
| RATED ROTATION SPEED(rpm) | 3600 | 3600 | 3600 | 3600 |
| DISPLACEMENT[ml(cu.in)] | 296(18.06) | 296(18.06) | 296(18.06) | 296(18.06) |
| FUEL TANK CAPACITY[L(gal.)] | 3.6(0.792) | 3.6(0.792) | 5.5(1.21) | 5.5(1.21) |
| FUEL COMSUMPTION[g(ml)/KW.h] | 283(336.9) | 283(336.9) | 283(336.9) | 296(352.4) |
| UNIT PRICE (FOB FUZHOU) | USD$ | USD$ | USD$ | USD$ |
>>
