CNC Leather Hole Punch Machine

Product Description

Product Description
Multi-type Punching Knife Machine
Main Features:
Multi-type punching knife for easy exchange, catering to individual needs.
New gantry structure for fast punching speed and silent operation.
Mechanical punching ensures original color and quality of leather.
Equipped with casters for easy machine movement.
Customized electronic control for seamless integration with other machines.
Industrial vacuum silent cleaner for easy removal of leather scraps.

Company Name: Tianjin Meifurui Technology Co., Ltd.
Punching Machine Technical Description/Configuration
Maximum Punching Speed: 1200 holes/min
Punching Tool Types: 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm round hole
Other Customized Tool Head Installation
Vacuuming
Pattern Reading Mode: U disk
Drive Motor: Servo motor
Power Supply: Three-phase 380V/50Hz or single-phase 220V
Drawing Format: DXF
Brush Function for Manual Sewing
Customizable Processing Area: 1000-2000mm
Customizable Number of Heads: 8 punching heads for doubled efficiency
Customizable Film Feed Device for Improved Efficiency
Provides Hundreds of Punching Programming Data
Company Name: Tianjin Meifurui Technology Co., Ltd.

	product name	specifications and models	remarks
1	Single head CNC punch	MFR-P-1.5-900*600	1 piece at a time
2	Double head CNC punch	MFR-P-2.5-900*600	2 piece at a time
3	Single head CNC punch	MFR-P-1.5-1200*800	1 piece at a time
4	Double head CNC punch	MFR-P-2.5-1200*800	2 piece at a time
5	Four head CNC punchi	MFR-P-4.5-900*600	4 piece at a time
6	Six head CNC punch	MFR-P-6.5-900*600	6 piece at a time

---
