| SAPPHIRE PULSE Radeon™ RX 580 8GD5 | |
| GPU | 2304 Stream Processors 14 nm FinFET 4th Graphics Core Next (GCN) 1366 MHz Boost Engine Clock |
| Memory | 256 bit Memory Bus GDDR5 Memory Type 2000 MHz, 8000 MHz Effective 8 GB Size |
| BIOS Support | UEFI BIOS |
| Displays | Maximum 5 Outputs |
| Output | 1 x DVI-D 2 x HDMI 2 x DisplayPort 1.4 |
| Resolution | 5120×2880 (60Hz) Pixel DisplayPort Resolution 2560x1600 (60Hz) Pixel Dual Link DVI Resolution 4096×2160(60 Hz) HDMI Resolution |
| API | OpenGL® 4.5 OpenCL 2.0 DirectX® 12 Shader Model 5.0 |
| Feature | AMD CrossFire FreeSync Technology AMD Eyefinity Quad HD Display (4K*2K Support) Black Diamond Choke AMD Liquid VR Technology AMD Xconnect ready DirectX™ 12 Optimized Radeon VR ready Premium HDR Ready Frame Rate Target Control NITRO Quick Connect system Dual-X Cooling Black Diamond Choke 4 Fuse protection Precision fan control Robust VRM Cooling Radeon Chill Radeon Relive |
| Cooling | Dual-X fans Two ball bearing |
| Form Factor | 2 Part Slot Occupied 230(L)X 125(W)X 40 (H) Dimension /mm |
| Power Consumption | <225W |
| OS | Windows 10 Windows 7 |
| System Requirement | 500 Watt Power Supply (Suggestion) 1 x 8-pin AUX Power Connector Blue-ray™ / HD DVD playback requires Blu-ray / HD DVD drive. PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with. |
| 1. Product | AMD Graphics Card-- SAPPHIRE | ||
| 2. Graphics Cores | SAPPHIRE NITRO+ Radeon RX 580 8GD5 Special Edition | ||
| 3. Architecture Model | Radeon RX 580 | ||
| 4. Core Code | Polaris 20 XTX | ||
| 5. Core Technology | 14nm | ||
| 6. Stream Processor | 2304 | ||
| 7. Frequency of Core | 1430MHz | ||
| 8. Frequency of Memory | 8400MHz | ||
| 9. Capacity of Memory | 8GB | ||
| 10.Type of Memory | GDDR5 | ||
| 11. Bit Wide of Memory | 256 bit | ||
| 13. Type of Interface | PCI Express 3.0 16X | ||
| 14. Heat Dissipation | 2 blade cooling | ||
| 15. Display Interface | 2*HDMI+2*DP+DVI | ||
| 16. Resolution (Max.) | 5120×2880(60Hz) Pixel DisplayPort | ||
| 17. Power (TDP) | 250W ( 8PIN + 6 PIN ) | ||
| 18. Recommend Power | 500W | ||
