FUJI Home House Villa Hotel Obsevation Panoramic Lift 5 Passenger Traction Medical Hospital Indoor Freight Residential Outdoor Apartment Building Elevators

Product Description

Home-use Elevator Series

We specialize in producing various kinds of passenger elevators, freight elevators, home-use elevators, hospital elevators and escalators & moving walkways

ALL PRODUCTS >

Product Parameters

Model No	GS-J01
Technical specifications of the Home-use elevator (Counterweight at side)
Persons	Capacity(kg)	Speed(m/s)	Model number	Inner Dimension W x D (mm)	Door Opening Size W x D (mm)	Shaft Size W x D (mm)
4	320	0.4	JSTJW320-12	900x1100	(Right opening) 800x2100	1550x1500
				1000x1000	(Center opening) 700x2100	1650x1400
5	400	0.4	JSTJW400-12	900x1200	(Right opening) 800x2100	1550x1600
				1000x1100	(Center opening) 700x2100	1650x1500

Capacity(kg)	Rate speed(m/s)	Top Floor Height (mm)	Pit Depth (mm)
320~400	0.4	≥3500	≥600

Product Function

· Group control for 2-8 elevators · Independent service for passengers · Automatic leveling against power failure (With storage battery) · Fireman operation · Automatic return to base station in fire alarm

· Automatic return when door opening & closing hindered · Mischief prevention function · Collective control operation · Delay closing operation · Attendant operation · Collective control of lighting and fans

Technical Specification

Technical Specification

The stability, reliability, security, durability and high performance for ZHUJIANG FUJI elevator are exactly the basic guarantee for its increasing market share

CONTACT US >

Certifications

CE & ISO

Product Advantages

Tell us what you want and we will customize it and offer perfect solutions

CONTACT US >

Production Process
Packaging & Shipping

Our company is equipped with high-end intelligent devices, production technologies, R&D center, training center and service center

CONTACT US >

Our factory

Customer Cooperation

FAQ

FAQ

Q1. Our Advantages

A1: Our factory was established in 1986, over 37 years history till now, We boasts experienced and professional
technical,production and sales teams.

Q2. About quotation

A2: Please send us inquiry from MIC, we will reply to you within 24 hours. It would be highly appreciated if you offer
us all elevator details so that you can get our quotation as soon as possible.

Q3. Payment Terms & Trade Terms

A3: T/T before and L/C at sight are approved. FOB/ CFR/ CIF are workable with the help of our reliable forwarder.
If you have your own forwarder, you can handle the shipment part by yourself.

Q4. What information is absolutely needed before asking for price?

A4: A. How many persons? (6 persons for 450kg,8 persons for 630kg, 10 persons for 800kg etc..) B. How many floors/ stops/ doors? C. What's the shaft size? (width by depth) D. Is there a machine room on the top of shaft? E. The step width, height and angle for escalator.

Q5. What about the packaging?

A5: All elevator parts will be packed into solid wooden cases. Generally, 1*20' container is enough to load 1 set of
elevator about 6 floors.

Q6. How to do with the elevator installation and maintenance?

A6: We can send engineers to your country (customers bear all charges) to guide the installation and then train the
workers about maintenance in the future. But in most situations, local workers can finish this work with our guidebooks
and technology support, or you can ask the local professional elevator engineers to do this job, This can save much
money for our customer. Of course, you can get support from our factory at any time.

---
