Product Details
Product Description
Product Description
Brand
| Power(Kw)
| Qty
|
|
|
Weifang Power
| 50
| 1set
|
|
|
Still sound box
| /
| 1set
|
|
|
With muffler, can work at high temperature of 50 degrees. The output power is sufficient and meets the power acceptance standard.
|
Supply list of diesel generator sets
| Details
|
| Details
|
1
| engine
| 2
| Electric generator
|
3
| 24V electric starting motor
| 4
| silencer
|
5
| Random spare parts
| 6
| Shock absorber
|
7
| charger
| 8
| Operation and maintenance manual
|
9
| Battery connection cable
| 10
| Pressure transducer
|
11
| Temperature sensor
| 12
| Speed sensor
|
13
| Instruction Manual
| 14
| Certificate of delivery
|
The configuration and technical parameters of the generator set
Item
| Details
|
Diesel generator set
|
rand of unit
| Weifang Power
|
Unit model number
| 50 KMS -
|
Manufacturer's name/address
| China
|
Rated power (KVA)
| 65
|
Rated output voltage (V)
| 400
|
Frequency (Hz)
| 50
|
Rated speed (rpm)
| 1500
|
Rated power factor
| 0.8（lag）
|
Rated current (A)
| 72
|
Class of insulation
| H GRADE
|
Class of protection
| IP21
|
Mode of connection
| Three phase four wire system
|
Unit weight (kg)
| 550
|
Unit size (length × width × height mm)
| 1730/600/1100
|
Noise dB(A)
| 75
|
Fuel consumption rate (g/kwh)
| 208
|
Start and stop modes
| Electric starting
|
Unit overhaul time (H)
| ＞10000
|
Diesel engine
|
Brand of engine
| Weifang Power
|
Origin of engine
| China
|
Number of cylinders
| 4
|
structure
| Straight line type
|
Speed regulation mode
| Mechanical speed regulation
|
Filtration system
| Adopt integral replacement type oil, diesel filter and air filter
|
Muffler and exhaust pipe
| Using the industrial muffler with high noise reduction efficiency, the noise of the unit can be reduced by 15~20dBA
|
Start up mode
| Start with 24V DC
|
Alternating current generator
|
Mode of excitation
| Brush self excitation
|
Insulation levels of rotor and stator coils
| H GRADE
|
Class of protection
| IP21
|
Quality of power
| G3 GRADE，GB/T2820
|
Voltage (V)
| 400
|
Voltage fluctuation (%)
| ≤0.5%
|
Voltage transient adjustment rate (%)
| +20%～-15%
|
Voltage steady-state adjustment rate (%)
| ≤±0.25%
|
Voltage stabilization time
| 4S
|
Rotational speed (rpm)
| 1500
|
Frequency volatility (%)
| ≤0.5%
|
Frequency transient adjustment rate (%)
| +10%～-7%
|
Frequency steady-state adjustment rate (%)
| 0~5%（adjustable）
|
Frequency stabilization time
| 3S
|
Waveform distortion rate
| ≤5%
|
Unit no-load voltage setting range
| 95%~105%Rated voltage
|
Random file
|
| Diesel engine instruction manual
| 1pcs
|
|
Alternator instruction manual
| 1pcs
|
|
Diesel generator set installation, use, maintenance manual
| 1pcs
|
|
Product quality certification documents
| 1pcs
|
|
