High Quality Double-Plate Non-Stop Screen Changer for Pelletizing/Granulating Machine

Product Description

Adopts advanced pressure seal technology, through the pressure of polymers to drive seal components, to achieve the best sealing effect and change screen more quickly.
Using high grade alloy steel, after nitriding process to extended product life span greatly.
Alternating work mode, can guarantee the material flow continuous, Stability and the process parameters of repeatability,when change the screen.
Modular combinations, suitable for different standard extrusion machine and convenient to clean.
Adopts the inner heating device, for safe and energy-saving. Fully enclosed wires, for elegant appearance

Simple operation and uncomplicated control

Reliable operation

Short polymer residence time

Leak-free operation mode

Low pressure consumption

Specification Parameter Table

Model	Output(Kg/h)	Filter size (mm)	Filtration area(cm2)	Heating zone	Heating power(KW)
FL-TB-150	400~1000	Φ155	176x2	6	22
FL-TB-180	700~1300	Φ185	254x2	6	28
FL-TB-200	850~1700	Φ205	314x2	6	35
FL-TB-250	1100~2200	Φ255	490x2	6	40
FL-TB-300	1200~2400	Φ310	706x2	6	60
FL-TB-350	1800~2200	Φ355	962x2	8	60
FL-TB-400	2000~3500	Φ307	1256x2	8	68

---
