Band7 50W Linear Amplifier RF Power Amplifier Module

Product Description

Band7 50W Linear Amplifier RF Power Amplifier ModuleProduct Features
• PA+LNA 10W RF power amplifier.
• Automatic level/gain control (ALC/AGC), high stability and Reliability.
• Power Amplifier with output short circuit or open circuit protection
• Intelligent monitoring, automatic alarm.
• Small size, light weight, Easy to operate and maintain.
Product Description
• Power amplifier modules are mainly used in mobile communication.
• High efficiency power amplifier module, attached to an aluminum sub carrier.
Electrical Specifications

Parameter	Specification
Port	Down	UP
Frequency Range	2620~2690MHz	2500~2570MHz
Saturated Output Power	47±1dBm	-10±1dBm
Gain	55±1dB	25±1dB
Gain Adjustable rang	≥20dB	≥20dB
Step of Gain Adjustable	≤1dB	≤1dB
Gain Flatness	≤2.0dB	≤2.0dB
Noise Figure	/	≤1.8dB
ACPR	-40dBc	-40dBc
EVM	≤5%	≤5%
Out of Band Spurious	9kHz~1GHz:≤-36dBm/30kHz 1GHz~12.75GHz:≤30dBm/30KHz
Gain Stability	±1.5dBm
Power stability	±1.5dBm
VSWR	≤1.5
DC Input Voltage	DC28±1.0V
Current Consumption	≤7.5A
Power and Monitoring port	5569-06A
Working Temperature	-25ºC~+55ºC
Storage temperature	-40ºC~+65ºC
Impedance	50Ω
RF connector	SMA
Monitor inerface	RS-485
Monitoring communication protocols	Use Manufacturers protocol or Customized
weight	0.5kg
Dimension	145×65×32mm
Surface Color	Metal color conductive oxide and other color customized

Product Dimensions

---
