Double Wall Fabric with 5cm10cm to 30cm PVC Drop Stitch

Product Description

Product			5cm	8cm	10cm	12cm	15cm	20cm
Pattern			Dot	Wave	Dot ,In-line	Dot	Dot ,In-line	Dot
Base Cloth			Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)
Space Length		cm	5 (+/-5%)	8 (+/-5%)	10 (+/-5%)	12 (+/-5%)	15 (+/-5%)	20
Material Total Weight		g/sq.m	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)
Tensile Strength (2 layers)		N/5cm	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)
Adhesion Strength (2 layers)		N/5cm	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)
Pressure	Recommended	PSI(lbs/inch2)	15	15	15	15	15	15
	Maximum	PSI(lbs/inch2)		30	3030	30	30	30
Standard Width		Metre		2.06	1.55/1.68	1.68/1.85	1.68/1.85	2.03
Surface			Matt	Matt	Matt	Matt	Matt	Matt
Length (standard)		Metre	30,100,150,250	30,100,150,250	30,100,150,250	30,100,150,250	30,100,150,250

Product Features:
1. High tension, high tensile force, good adhesion, high peel strength and strong composite fastness;
2. Strong, aging resistant, tortuous tear;
3. Anti-mildew, anti-corrosion, anti-corrosion;
4. Waterproof, cold resistant, anti-static, anti-radiation, anti-UV;
5. Flatness, safety, transparency, and good hand feeling ;
6. Widely used in inflatable boats, kayak, inflatable skateboards, inflatable toys, lifeboats, advertising cloth, water and underwater sports equipment, as well as soundproof walls, shock absorbers and other lightweight cargo inflation In the support.
Specifications:
Available size
Height: 5cm,8cm,10cm,12cm,15cm,20cm,30cm
Width: up to 2.10m
Weight: 2600gsm
Packing size: 30m/roll or customized
Thickness and color make to order
Technical data:

Product			5cm	8cm	10cm	12cm	15cm	20cm
Pattern			Dot	Wave	Dot ,In-line	Dot	Dot ,In-line	Dot
Base Cloth			Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)	Polyester 500D( High tensile)
Space Length		cm	5 (+/-5%)	8 (+/-5%)	10 (+/-5%)	12 (+/-5%)	15 (+/-5%)	20
Material Total Weight		g/sq.m	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)	2700 (+/-200)
Tensile Strength (2 layers)		N/5cm	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)	4100 x 2800 (+/-300)
Adhesion Strength (2 layers)		N/5cm	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)	150 x 150 (+/-20)
Pressure	Recommended	PSI(lbs/inch2)	15	15	15	15	15	15
	Maximum	PSI(lbs/inch2)		30	3030	30	30	30
Standard Width		Metre		2.06	1.55/1.68	1.68/1.85	1.68/1.85	2.03
Surface			Matt	Matt	Matt	Matt	Matt	Matt
Length (standard)		Metre	30,100,150,250	30,100,150,250	30,100,150,250	30,100,150,250	30,100,150,250

Fields of Application :
1. Inflatable boat bottom
2. Surfing board
3. Air mat
4. Bed mattress
5. RV car mat.
Inflatable swimming pool
Bedding, Mattress, air deck, surfboard, bed mattress, sup board, inflatable paddle board

---
