Zinc Alloy Die Cast Single Pulley with Nylon Wheel

Product Description

Product Description
Zinc Alloy Die Cast Pulley Single/Double Wheel Rigid Eye with Steel wheel
Zinc Alloy Die Cast Pulley Single/Double Wheel Rigid Eye with Nylon wheel
Zinc Alloy Die Cast Pulley Single/Double Wheel Swivel Eye with Steel wheel
Zinc Alloy Die Cast Pulley Single/Double Wheel Swivel Eye with Nylon wheel
Technical Data and Dimensions
Zinc Alloy Die Cast Pulley Single Wheel with Nylon wheel

Size	Total Length	Eye Dia.	Weight Each
(mm.)	(mm.)	(mm.)	(Kg.)
15	49	10	0.021
20	59	11	0.036
25	70	12	0.052
30	76	13	0.077
40	90	16	0.110
50	110	17	0.175
65	133	18	0.360

Zinc Alloy Die Cast Pulley Double Wheel with Nylon wheel

Size	Total Length	Eye Dia.	Weight Each
(mm.)	(mm.)	(mm.)	(Kg.)
15	49	10	0.034
20	58	11	0.055
25	70	12	0.072
30	80	13	0.115
40	90	16	0.190
50	100	17	0.293

Zinc Alloy Die Cast Pulley Double Wheel with Steel wheel

Size (D)	Rope Dia.	Weight Each
(in.)	(in.)	(Kg.)
1/2	5/32	0.028
3/4	3/16	0.040
1	1/4	0.073
1-1/4	5/16	0.126
1-1/2	3/8	0.142
2	7/16	0.283

Zinc Alloy Die Cast Pulley Single Wheel with Steel wheel

Size (D)	Rope Dia.	Weight Each
(in.)	(in.)	(Kg.)
1/2	5/32	0.028
3/4	3/16	0.040
1	1/4	0.073
1-1/4	5/16	0.126
1-1/2	3/8	0.142
2	7/16	0.283

*Other main type of Blocks are in following picture. You can contact our sales for products details.
BUSINESS FAQ:
1) What is the MIN order quantity ?
USD 1580 in total value, usually 1 ton.
2)What is the delivery time?
15 -20 days since received the deposit.
3)What is the Payment term?
A. 30% TT deposit, the balance against copy B/L.
B. Irrevocable L/C at sight.
C. Other payment can be negotiated.
4)Could I get free samples before first cooperation?
Yes, of course! But the buyer need to afford express fee, which is returnable once we build cooperation.
5)What's the packing method?
Packing methods for most of the products are in the cartons or polywood case.Special packages are available upon
customers'need. You can contact us for special or more detailed packages.
Why choose Lift-Sunny (lift-sunny.en.made-in-china.com)
1). "ONE-STOP" Rigging and Marine supplier: a great variety of rigging and marine products including 1,000 kinds
of products, 3,000 kinds of specifications, which are widely used in Construction,Transportation, Forestry, Oil&Gas,
Agriculture, Utilities, Aerospace, Marine, Manufacturing, Mining, Fishing and Government.
2). Old history: since 1986, more than 30 years focus on rigging, marine and rubber products.
The founding principles of the company have never changed-business integrity,quality is everything.
3). Strong development capabilities: processing with Given materials and samples at own
module workshop, save cost, finish customers special and big order rapidly.
4). 4 round Superior Quality Control with 10 years records and zero complaint:
4 round quality inspection including raw materials, production, finished products, final package, have a thorough
quality control system, professional staff, every step is under strict inspection, to insure
that every product is perfect.For the individual and mass production part, the records which include the
sub-contractor records will be retained at least 10 years since the record has been made,
(e.g. inspection/test record, control plan, etc)
In the past years,the complaint rate of product quality from more than 50 countries customers is zero.
5). Certificate of Quality: ISO9001, CE, GS, CCS, ABS, BV, KR, REACH, etc. Photos as below.
6). Reasonable and Competitive price compared with others with same quality.
7). Fast Delivery time: within 20 days for most products.
8). Comfortable and topping after-sales service with 99.8% satisfaction rate for more than
50 countries and regions: We will send you "Customer Satisfaction Inventory" after you receive our first order.
If you are not satisfied with our quality,price or service, please list your comments or suggestions, the next day, our
senior manager will personally call you or email you, apologize to you, to solve your problem.Because day after day,
year after year of self-correction, our current customer satisfaction rate has reached 99.8%. we are very proud of this.
Of course, we still need to continue to work hard.Our main marketing as below picture.
9). Great Supports for marketing. With us, your money and business in safe.If you want to be
No.1 you should contact with us right now!

---
