Excavating Machinery 33 Ton Hydraulic Excavator Digger for Sale

Product Description

Highlights
Heavy duty Undercarriage
With X-shaped frame built from high strength tensile steel, the undercarriage is designed to withstand the toughest conditions.Continuous digging, lifting and loading can put excessive stress on machines. The SWE330LC has a long track beam and crawler system that guarantees greater stability. The structure also helps protect key components such as the travel motor from undue stress.
Tougher Components
The undercarriage components are tougher too. Heavy duty rollers,reinforced idler frame and optional full track guard guarantee the integrity of our undercarriage. It's this core strength that enables our customers to keep working and earning - around the clock.
Stronger Upper Structure
The upper structure of the SWE330LC is built around a reinforced and well-engineered H-beam, allowing the boom to be mounted exactly in the center of the machine. This central positioning helps the boom cope with more stress on the attachment group. It also means better distribution of weight and tension along the entire machine.
Product Show
Specifications

Engine
Model	CUMMINS
Type	Six-cylinder,water-cooled, turbocharged,mechanical injection
Rated power	166KW
Rated speed	2200rpm
Main Technical Specification
Operating weight	33000Kg
Standard bucket capacity	1.53m3
Slewing speed	11rpm
Stick digging force	104KN
Bucket digging force	137KN
Travelling System
Travelling speed	2.9-5.1km/
Grade ability	65%
Ground pressure	0.069MPa
Dimensions
Overall length	11140mm
Overall width	3280mm
Overall height of boom	3540mm
Overall height of cab	3010mm
Engine cover height	2650mm
Counterweight clearance	1235mm
Ground clearance	470mm
Upperstructure width	2960mm
Rear-end length/Slewing radius	3215mm
Overall track length	4690mm
Track length on ground	3780mm
Track gauge	2580mm
Track width	600mm
Boom slewing angle(L/R)	0o
Operating Scope
Arm length	3200mm
Max. cutting height	10215mm
Max. dumping height	7390mm
Max. digging depth	7625mm
Max. reach	11300mm
