| Model | Unit | XE75GA | ||
| Operating weight | Kg | 7700 | ||
| Bucket capacity | m³ | 0.33 | ||
| Engine | Model | / | V2607 | |
| Direct injection | / | √ | ||
| Four strokes | / | √ | ||
| Water cooled | / | √ | ||
| Turbocharged | / | √ | ||
| Air to air intercooler | / | / | ||
| Number of cylinders | / | 4 | ||
| Rated power/speed | kw/rpm | 36/2000 | ||
| Maximum torque/speed | N.m | 206.9/1100-1500 | ||
| Piston displacement | L | 2.615 | ||
| Main performance | Travel speed(H/L) | km/h | 4.3/2.5 | |
| Swing speed | r/min | 11 | ||
| Gradeability | ° | ≤35 | ||
| Ground pressure | kPa | 33.5 | ||
| Bucket digging force | kN | 57 | ||
| Arm digging force | kN | 38 | ||
| Maximum tractive force | kN | 68.3 | ||
| Boom offset(Left) | ° | / | ||
| Boom offset(Right) | ° | / | ||
| Hydraulic system | Main pump | / | / | |
| Rated flow of main pump | L/min | 160 | ||
| Relief valve setting pressure | MPa | 28 | ||
| Travel system pressure | MPa | 27.4 | ||
| Swing system pressure | MPa | 18.6 | ||
| Pilot system pressure | MPa | 3.5 | ||
| Oil Capacity | Fuel tank capacity | L | 170 | |
| Hydraulic tank capacity | L | 76 | ||
| Engine oil capacity | L | 10 | ||
| Appearance size | A | Overall length | mm | 6185 |
| B | Overall width | mm | 2265 | |
| C | Overall height | mm | 2645 | |
| D | Width of platform | mm | 2260 | |
| E | Track length | mm | 2825 | |
| F | Track width | mm | 2250 | |
| G | Standard track shoe width | mm | 450 | |
| H | Track wheelbase | mm | 2195 | |
| I | gauge | mm | 1800 | |
| J | Counterweight ground clearance | mm | 813 | |
| K | minimum ground clearance | mm | 385 | |
| L | Minimum tail turning radius | mm | 1840 | |
| M | Track height | mm | 696 | |
| Working scope | A | Maximum digging height | mm | 7085 |
| B | Maximum unloading height | mm | 5160 | |
| C | Maximum unloading height | mm | 4020 | |
| E | Maximum vertical digging depth | mm | 2960 | |
| F | Maximum digging radius | mm | 6260 | |
| G | Minimum turning radius | mm | 1818 | |
| H | Maximum dozer blade lifting height | mm | 748 | |
| I | Maximum dozer blade cutting depth | mm | 363 | |
| Equipment | Standard | Boom length | mm | 3720 |
| Stick length | mm | 1622 | ||
| Bucket capacity | m³ | 0.33 | ||
| Optional | Boom length | m³ | / | |
| Boom length | m³ | / | ||
| Bucket capacity | m³ | / | ||
