15 Tons New Cummins Engine Xe150d Small Excavator with Hammer

Product Description

15 Tons New CUMMINS engine Xe150d Small Excavator with Hammer
Product description XE150D hydraulic excavator is a new product developed by the factory which is widely developed by adopting the latest technology and adopting the advanced technology of similar foreign products. It is an efficient excavator with the latest technology, full attention to safety and environmental performance, and extremely high production efficiency. Based on the full absorption of international advanced technology, the project is based on independent innovation and comprehensively overcomes many core key technologies of 15 ton hydraulic excavators.

1. Ecological and economical
* Customized exclusive engine can meet Euro stage IV Emission Standard. * Well-known hydraulic components, higher efficiency.
* Minicomputer control technology makes operation more economical.
2. Multiple applications
* Different boom, arm and bucket combinations can provide excellent all-around versatility.
* Multi-functional work tool system can meet various operational requirements including digging, breaking and so on.
3. Comfortable operating experience
* Air conditioner and heater ensure the appropriate temperature.
* Air-suspension seat equipped with electric heating function.
* Integrated control panel and large display screen provide multiple information.
Technical parameter

Description		Unit	Parameter value
Operating weight		kg	14600
Bucket capacity		m³	0.32~0.71
Engine	Model	Engine	CUMMINS
			QSF3.8
	No. of cylinders	---	4
	Output power	kW/ r/min	93/2200
	torque/speed	N.m	500/1300
	Displacement	L	3.76
Main performance	Travel speed(H/L)	km/h	5.3/3.2
	Gradeability	%	70
	Rotary speed	r/min	11.7
	Ground pressure	kPa	37
	Bucket digging force	kN	106.9
	Arm digging force	kN	73.4
Hydraulic system	Main pump	--	K7V63DTP
	Rated flow of the main pump	L/min	2×123.5
	Main safety valve pressure	MPa	34.3/37
	The pressure of the pilot system	MPa	3.9
Oil Capacity	Fuel tank capacity	L	260
	Hydraulic tank capacity	L	105
	Engine oil capacity	L	11

Product image
