X5032 X5040 Universal Milling Machine Price

Product Description

VERTICAL MILLING MACHINE FEATURES:
The machine is suitable for machinery, light industry, instrument, motor, electrical appliance and
moulds, and widely used in milling plane, inclined plane and slot on miscellaneous work pieces
of various metals by means of cylindrical or angle milling cutter in either down-milling or up-milling.
It is characterized by stabilizing precision, sensitive response, light in weight, power feed and rapid
adjustment in longitudinal, cross, vertical traverse.
Vertical milling machine is suitable for milling various metals. It can mill plane, inclined plane, groove,
keyway and also can drill and bore with special equipment. The machine introduces ball screw drive
and higher spindle speed. Every kind of vertical milling machine can be equipped with digital display.
STANDARD ACCESSORIES:
1. ISO50 Milling chuck
2. ISO50 Cutter arbor
3. Inner hexagon spanner
4. Double head wrench
5. Single head spanner
6. Oil gun
7. Draw bar
SPECIFICATIONS:

MODEL	UNIT	X5040
Table size	mm	400X1700
T-slots(NO./Width/Pitch)		3/18/90
Longitudinal travel(manual/auto)	mm	900/880
Cross travel(manual/auto)	mm	315/300
Vertical travel(manual/auto)	mm	385/365
Rapid feed speed	mm/min	2300/1540/770
Spindle pore	mm	29
Spindle taper		7:24 ISO50
Spindle speed range	r/min	30~1500
Spindle speed step	steps	18
Spindle travel	mm	85
Max.swivel angle of vertical milling head		±45°
Distance between spindle nose and table surface	mm	30-500
Distance between spindle axis and colomn guideway	mm	450
Feed motor power	kw	3
Main motor Power	kw	11
Overall dimensions(L×W×H)	mm	2556×2159×2258
Net weight	kg	4250/4350

Company Profile:

Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008.

The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale.

Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills.

---
