Gap Bed Lathe Machine Gh1440W Gh1640W

US$2,000.00-2,300.00 1 Piece (MOQ)

Basic Info.

Model NO.

GH1840 GH1860 GH2060 GH1440W GH1640W

Type

Horizontal Lathe

Processing Accessory

Metal

Guide Rail

Horizontal Guide Rail

Tool Holder

4 Way Tool Post

Power Source

Electric

Controlling Mode

Artificial

Automatic Grade

Manual

Setting Mode

Floor-type

Precision

High Precision

Certification

CE, RoHS, ISO 9001

Condition

New

Max.Swing Over Bed

410mm

Swing Over Cross Slide

224mm

Width of Bed

260mm

Spindle Taper

Mt6

Spindle Bore

52mm

Transport Package

Plywood Case

Specification

3200kgs

Trademark

HOYONG-TRD

Origin

Shandong, China

HS Code

84581900

Production Capacity

10 PCS/Month

Product Description

GAP BED LATHE MACHINE FEATURES:
Supersonic frequency hardened and accurate grinded bed way.
12 steps of spindle speed.
52mm spindle bore
2.4kw(3HP)main motor power
Foot brake giving rapid braking
Lathe has scream button
Inching turning spindle is facilitate to shift gears ,load or unload workpieces
Special designed chip pan easily to remove chips
The lathe has safety switch to break power automatically when changing gears or belts
FEATURES:

MODEL			GH-1640W	GH-1440W
General Capacity	Max.Swing.over bed	mm	410mm(16)	356mm(14)
	Max.Swing.over cross slide	mm	224(8-8/9)	210(8-5/8)
	Max.Swing.over gap	mm	580(22)	506(20)
	Bed width	mm	260(10)
	Distance between centers	mm	1000(40)
Spindle	Taper of spindle bore		MT#6	MT#5
	spindle bore	mm	52(2)	40(1-1/2)
	Steps of spindle speeds		12steps
	Range of spindle speeds	r/min	40-1800rpm
	Spindle nose		D-6	D4
Threading & Feeding	Metric thread range	mm	0.45-7.5(22kinds)
	Inch screw thread range	TPI	4-112(40kinds)
	Range of longitudinal feeds	mm	0.03-0.688(0.0011-0.0271in/rev)
	Range of cross feeds	mm	0.015-0.220(0.0003-0.01in/rev)
Tailstock	Travel of tailstock quill	mm	100(4)
	Diameter of tailstock quill	mm	50(1-24/25)
	Taper of tailstock quill		MT#3
Power	Main motor power	Kw	2.4(3HP)
Power	Coolant pump motor power	Kw	0.04(0.055HP)
Packing size (LxWxH)		mm	1970X760X1510	1470X760X1510
Net Weight		Kg	960	740
Gross Weight		Kg	1090	870
