Woodworking Plywood Veneer CNC Rotary Peeling Clipping Lathe Machine

Product Details

Product Description

Product Description
I. Machine Features
1. Spindleless veneer peeling machine is used for making panel core veneer .
2. It is suitable for the eucalyptus, pine, cotton wood and another wood logs.
3. The quality of the veneer determines the quality of the plywood, so controlling the quality of the veneer is the premise and the most important part of producing standard plywood. Core Veneer peeling machine is a very technical equipment in plywood line equipment.
4. This machine is high speed peeling machine, the speed can up to 120m/min. It works stable even at high working speed.
II. Technical Parameters

DESCRIPTION	UNIT	PARAMETERS
Model No.		BQS1814/500HK
Log peeling length	mm	970mm-1500mm
Log peeling diameter	mm	500mm-20mm
Veneer thickness range	mm	0.3mm-6.0mm
Linear speed of host machine	m/min	0-120M/Min(Frequency adjustable)
Motor powers	KW	Double roller 7.5Kw+7.5Kw Single roller 5.5kw+5.5kw Feeding motor 7.5KW(Servo motor) Clipper motor 2.2kw(Servo motor) Belt conveyor 2.2kw
Speed reducer		R87 harden helical gear reducers
Rollers specification	mm	Ø125mm x 1500mm (Harden chroming thicker)
Machine overall size	mm	5100mm x 1900mm x 1550mm
Machine weight	kg	7200kgs
Main function	Automatic peeling speed adjustable function Final veneer automatic cutting function Japan smc guide rail air cylinder Japan NSK bearings Ø90mm Alloy screw and tin bronze nut Harden full closed oil immersion guide bars (Free maintenance)

---
