Double Shaft Paddle Mixer for Fish Meal Organic Fertilizer Grain Masala Mixer Machine

Product Description

Double shaft paddle mixer for fish meal organic fertilizer grain masala mixer machine Product Description Small model: Big model: The BSL masala mixer machine is equipped with 2 horizontal paddle shafts, there are paddles on each shaft. Driven by the directly-connected reducer, 2 paddle shafts rotate reversely to make paddle move fast. The rotating paddle generates centrifugal force during high speed rotation, spilling the material to the upper part in the barrel, then material falling down (the vertex of material is in a so-called instant non-gravity state). Driven by the blades, material is mixed back and forth to make it evenly.
If the material is large, the mixer can add shear blades, then the big material can be broken up, scattered, obtained satisfactory mixing effect via the shear blades in a relatively time. Technical data of BSL grain mixer machine:

Model	Work volume(L)	Speed(rpm)	Motor power(KW)	Overall size (L*W*H) (mm)	Weight (kg)	Output size (mm)
BSL-100	60L	2*57	3	1320*700*700	320	2*200*50
BSL-300	180L	2*57	4	1242*1278*1025	750	2*250*60
BSL-500	300L	2*51	5.5-7.5	1412*1410*1230	1000	2*300*80
BSL-1000	600L	2*43	11-15	1875*1610*1350	1550	2*350*120
BSL-2000	1200L	2*43	18.5-22	2312*2160*1775	2500	2*350*120
BSL-3000	1800L	2*36	22-30	2408*2400*1955	2900	2*350*120
BSL-4000	2400L	2*36	30-37	2822*2546*2015	3600	2*360*140
BSL-6000	3600L	2*29	37-45	3075*2980*2235	5600	2*700*140
BSL-8000	4800L	2*29	45-55	3278*3426*2425	7100	2*700*140
BSL-10000	6000L	2*29	55-75	3538*3645*2615	8000	2*800*140

Details Images Safety net: There is a safety net on the cover, so that operator cannot reach out arms into the mixer, danger can be prevented. Paddle shafts inside the mixer: make the mixing effect better. Seals on both sides of mixer: PTFE packing seals (packing) are adopted on both sides of our paddle mixer, so powder will not leak into bearing and powder leakage will not happen. Discharge part: Pneumatic valve is adopted to discharge material. Mixing dry powder or powder with a little liquid are applicable. Photoelectric proximity switch. (safety function) Photoelectric proximity switch (approach switch) is adopted on the cover of the mixer, If cover is opened or about to be opened,
mixer will stop working immediately automatically. This function will keep operators safe well. TO ACHIEVE BEST QUALITY. 1) We use motor from DaZhong/ABB/Siemens/WEG.
2) We adopts electrical control parts from
3) We use bearings from Client's feedbacks of mixer machines: Company Information Brightsail spice & herb machinery Co.,Ltd focuses on one-stop overall solutions for spice&herb product processing.
The solution covers from cleaning machine,cutting machine,dryer, roaster, crusher, grinding mill,mixer,to filling and packing machines...etc.
Till 2022 year, we have exported our machines to more than 75 countries around the world and have received a lot positive feed-backs from our customers.
Besides, we also provide other solutions for food and chemical powder processing. Packaging & Shipping Export standard package. Fumigation wooden box or container.
For small machine, we pack it in wooden box.
For super big machine, we will separate the machine into several parts and pack it with film. Then, fix them in container with steel to avoid any shaking or moving during the shipping. Our Service FAQ To recommend you a suitable model of mixing machine, please answer the questions below. 1) What material you will mix?
2) How many L or kg per batch you need to mix? Do you know the density (g/cm3) of mixing material?

---
