Hongcheng Formply F17 a Solution Developed Specifically for Australia

Product Description

Product Description

Construction:	Panel code: 17-10-11 17 mm nominal thickness 1.0 mm face veneer 11 plies
Film:	60/ 165 g/m2 black phenolic resin coating, 2 sides
Glue bond:	Phenolic resin. A-bond.
Edge seal:	Edges are sealed with 2 layer acrylic paint
Stress Grade:	F17, Applies in both the parallel and perpendicular directions to the grain.
Standard:	AS 6669 - 2007 Plywood - Formwork
Finish:	Capable of a Class 2 off-form finish on first pour when used in conjunction with good site and formwork practices and AS 3610 (subject to conditions).
Formaldehyde Emission:	Super E0
Environmental:	Bsi Benchmark Certified
Tolerances:	Thickness: +/- 0.5 mm Squareness: +/- 1.0 mm

Detailed Photos
Product Parameters

Stress Grade	Nominal Thickness (mm)	Dimension (mm)	Weight (kg/sheet)	Parallel to face grain		Perpendicular to face grain		Packing Unit (sheets)
				Moment of inertia	Section modulus	Moment of inertia	Section modulus
				I (mm4 /mm)	Z (mm3 /mm)	I (mm4 /mm)	Z (mm3 /mm)
F17	17	1800 x 1200	23	230.0	26.8	176.0	22.5	40
F17	17	2400 x 1200	31	230.0	26.8	176.0	22.5	50

Our AdvantagesHongCheng Formply is a high quality film faced plywood developed and engineered specifically for the Australian market. With a three tier quality control program comprising; a detailed 'Manufacturing Specification' adhered to by trained staff; more than ten years experience quaily control teams; and regular, detailed and recorded in laboratory testing on key quality requirements. HongCheng Formply provides assurance of quality and consistency. All veneer in the manufacture is certified Forest Stewardship Council from sustainable forests.
Certifications
Packaging & ShippingPackaging:
Inner with waterproof plastic bag, outside with plywood or carton, then fastened with 3'x6' sheet iron and packed with pallets
Shipping:Specialist Transportation Service TeamWe could control the production to delivery on time.After Sales ServiceHow to cut the the best from HongCheng film faced plywood?
Storage
Always clean and repair the formwork panels before storage, the formwork should then be stacked off the ground on level supports and under cover. framed formwork panels should be stacked alternately face and back to back to avoid face damage by bolts etc. if panels are wet, do not allow them to dry too rapidly.
Sealing of edges
Phenolic film faced plywood edges are fully sealed by the factory and it is the most important that all edges remain sealed. to obtain full value from a phenolic film faced plywood sheet any recut edges should sealed as soon as possible with water proof paint sealing of holes.
any hole made in film faced formwork panels should also be sealed to prevent water entering. if water does enter it may cause swelling around the holes.
Cleaning and repair
To obtain full life, cleaning should be carried out immediately after each use. phenolic film faced plywood may be wiped with release agent or cleaned with water and stiffbrush. it may be necessary to use a hard wood scraper but care should be taken not to damage the plywood face. do no use a wire brush or sharp metal scraper to dislodge hardened concrete.

---
