Lty80s-1t Extrusion Blowing Molding Machine for 30L Bottle

Product Description

CHANGZHOU LOYALTY INDUSTRY CO.,LIMITED is specialized in Extrusion Blow Molding field. We provide blow molding machines, hollow moulds, auxiliary machines, special processing devices and project service for your production plans.We a professional manufacturer of Extrusion Blow Molding Machines, owning more than 16 years working experience in EBM machines' design, manufacturing, overhauling, service and project solutions. Our product line covers 0~30L continuous EBM models, high speed automatic EBM models, 30~500L accumulating EBM models, 1000~3000L large EBM models. Our machines are widely used in packing and producing industries of chemical, food & drinking, medical, automobile, traffic safety, recreation facility, family life and communal facilities. We provide the entire solutions for a whole producing line of project items.
Besides our Chinese domestic market, our blow molding machines also have been exported to Europ, Mid East, Africa, South America and Asia countries. The service covers product analysis, project sonsultation, manufacturing follow-up, exporting and after sales services.
We have mature technology and technics for multi-layer co-extrusion, high speed and high automatic blow molding machines, also can help our customers for producing line layout and producing flow arrangement. Our machines' quality is good and reliable, the working lifespan is more than 20 years. We hope to establish long term cooperation relationship with you and keep developing together.

1	LTY80S-1T is single station view stripe blow molding machine for 30L as maximum.
2	Output for 850 grams 20L stackable jerrycan is 50 Pcs/hour, daily capacity 1200 Pcs.
3	Output for 1KG 25L stackable jerrycan is 48 Pcs/hour, daily capacity is 1150 Pcs.
4	Continuous extrusion single head of transparent line design with refined metal process.
5	High efficiency extrusion system generally suitable for LDPE, HDPE and PP material.
6	Adopt nether bent arm central clamping unit guided with linear rails for platen moving.
7	Optimized hydraulic system with mechanical shuttle valve for platen moving stability.
8	Fast responding machine total control system with 100 point parison thickness control.
9	It's suitable for on-line auto deflashing mould and cancave handle trimming device.
10	Lubrication system, product clamping boards and scraps slide channels are included.

COMPONENTS	BRAND	ORIGIN
MACHINE TOTAL CONTROL	WISETECH	HONGKONG
100 POINT PARISON CONTROLLER	WISETECH	HONGKONG
7.5" COLORFUL TOUCH SCREEN	WISETECH	HONGKONG
TEMPERATURE CONTROL MODULE	WISETECH	HONGKONG
PARISON SERVO VALVE	ATOS	ITALY
PARISON SERVO TRANSDUCER	GEFRAN	ITALY
CONTRACTOR	SCHNEIDER	FRANCE/CHINA
AIR SWITCH	SCHNEIDER	FRANCE/CHINA
FUSE KIT	SCHNEIDER	FRANCE/CHINA
PROXIMITY SWITCH	RIKO	TAIWAN
INVERTER	DELTA	TAIWAN
SEAL PARTS	DZ	TAIWAN
HYDRAULIC PUMP	HYTEK	TAIWAN
HYDRAULIC VALVE	HYTEK	TAIWAN
PNEUMATIC VALVE	AIRTAC	TAIWAN
PNEUMATIC CYLINDER	AIRTAC	TAIWAN
COMPRESSED AIR FILTER	AIRTAC	TAIWAN
LINEAR GUIDE RAILS	HIWIN	TAIWAN
HARD GEAR BOX	HAOKE	CHINA
EXTRUSION MOTOR	XINDALI	CHINA
HYDRAULIC MOTOR	SIEMENS BEIDE	GERMANY/CHINA

	SPECIFICATIOIN	/PARAMETER
	Max Product Volume	30 L
	Dry Cycle Time	7.5 Second
	Pre-heating Time	3-3.5 Hours
	Machine Weight	8.8 T
	Machine Size	4.6*2.45*2.95 m
/EXTRUSION UNIT
	Extruder Distribution	Main Screw	View Stripe Screw
	Screw Diameter	80 mm	25 mm
	Length/Diameter Ratio	24:1	24:1
	Heating Zone No.	5	2
	Heating Power	20.2 KW	1.2 KW
	Cooling Fan No.	4	-
	Fan Power	0.15 KW*4	-
	Extrusion Motor Power	30 KW	1.5 KW
	Plasticizing Capacity	110 Kg	7 Kg
/CLAMPING UNIT
	Clamping Design	Nether Bent Arm with Linear Rails
	Clamping Force	180 KN
	Platen Size	650*730 mm
	Platen Moving Distance	750 mm
	Platen Opening Stroke	450-950 mm
	Max Mould Size	650*650 mm
	Mould Thickness	460-550 mm
/HEAD UNIT
	Head Type	View Strpe Continuous Single Head
	Head Cavity No.	1			2
	Central Distance	-			250 mm
	Max Die Diameter	250 mm			130 mm
	Heating Zone No.	2+1			2+1
	Heating Power	11 KW			9.6 KW
/ENERGY CONSUMPTION
	Extrusion Motor Power	31.5 KW
	Oil Pump Motor Power	15 KW
	Thickness Servo Motor Power	4 KW
	Extrusion Heating Power	21.4 KW
	Head Heating Power	7 KW
	Cooling Fan Power	0.6 KW
	Total Power	79.5 KW
	Average Energy Consumption	39.5 KW
/REFERENCE
	Cold Water Needed	0.3 Mpa		5500 L/h
	Compressed Air Needed	0.8 Mpa		1.2 M3/min
	Installation Capacity	250 Amp, 3*35 m+ 1*25 m
	Loading Reference	40' GP*1

---
