| Max dia | MM | 2500 | 3150 | 4000 |
| Table dia | MM | 2250 | 2830 | 2830/3150 |
| Max workpiece height | MM | 1600 | 1600 | 2000 |
| Max workpiece weight | T | 10/20 | 10/20 | 10/20 |
| Max torque of table | KN.M | 63 | 63 | 63 |
| Table rotate speed range (16step) | R/MIN | 2-63 | 2-63 | 2-63 |
| Max cutting force of the vertical holder | KN | 32 | 35 | 35 |
| Vertical toolholder move limit | = | ±30° | ±30° | ±30° |
| Range of feed rates(stepless) | MM/MIN | 0.1-500 | 0.1-500 | 0.1-500 |
| Horizontal travel of rail head | MM | 1400 | 1725 | 2150 |
| Ram travel of rail head | MM | 1000 | 1000/1250 | 1000/1250 |
| Fast moving speed of tool heads | MM/MIN | 3500 | 3500 | 3500 |
| Knife rod cross-section size (W.D.) | MM | 40x50 | 40x50 | 40x50 |
| Main motor power | KW | DC/AC:55 | DC/AC:55 | DC/AC:55 |
| Overall size of machine | CM | 540x470x480/520 | 605x440x493/533 | 690x510x480/ 520/570 |
| Weight of machine | T | 38 | 40/42 | 50/52 |
| Ram section | MM | 240x240 | 240x240 | 240x240 |
