ASTM B265 Tc1 Tc2 Tc3 R56540 5mm 8mm 10mm Thickness Titanium Plate/Titanium Sheet/Titanium Round Square Block

Product Description

Product Description The density of titanium is 4.506-4.516g/cm^3, melting point is 1668, boiling point is 3535. Therefore Titanium have low weight, excellent high strength and nonmagnetic festures, low density, excellent corrosion resistance features, high specificate strength and high temperature resistance features, so it is widely used in chemical industry field, medical field, electronics manufacture, mechanical parts field, automobile industry, and aerospace field, etc.

Grade	TA1, TA2, TA3, TA4, TA10, TA15, TA17, GR1, GR2, GR3, GR4, GR5, GR7, GR9, GR11, GR12
Size	T (0.6mm - 2.0mm) * W (1000mm) * L (3000mm max)T (3.0mm- 5.0mm)*W (1250mm)* L (3500mm max) T (6.0mm - 60mm) * W (2500mm max)* L (7000mm max)
Standard	ASTM B 265, ASME SB265 AMS491
Application	Chemical, industry, sports etc.
Feature	High corrosion resistance, low density, good thermal stability
Surface	Bright, Polished, Pickling, Acid cleaning, Sandblasting
Quality and test	Hardness test, Bending test, Hydrostatic etc.
Finish	Roll-up(Hard)
Surface	Polished

Chemical Composition (%)

1.Chemical requirements
Grade	N(≤)	C(≤)	H(≤)	Fe(≤)	O(≤)	Al(≤)	V(≤)	Pd(≤)	Mo(≤)	Ni(≤)	Ti
GR1	0.03	0.08	0.015	0.2	0.18	/	/	/	/	/	bal
GR2	0.03	0.08	0.015	0.3	0.25	/	/	/	/	/	bal
GR3	0.05	0.08	0.015	0.3	0.35	/	/	/	/	/	bal
GR4	0.05	0.08	0.015	0.2	0.4	/	/	/	/	/	bal
GR5	0.05	0.08	0.015	0.4	0.2	5.5~6.75	3.5~4.5	/	/	/	bal
GR7	0.03	0.08	0.015	0.3	0.25	/	/	0.12~0.25	/	/	bal
GR9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	/	/	bal
GR12	0.03	0.08	0.015	0.3	0.25	/	/	/	0.2~0.4	0.6~0.9	bal
GR23	0.05	0.08	0.012	0.25	0.13	5.5~6.5	3.5~4.5				bal

Mechanical property

2.Tensile requirements
Grade	Tensil strength(≥)		Yeild strength(≥))		Elongation(≥)%)
	ksi	Mpa	ksi	Mpa
GR1	35	240	20	138	24
GR2	50	345	40	275	20
GR3	65	450	55	380	18
GR4	80	550	70	483	15
GR5	130	895	120	828	10
GR7	50	345	40	275	20
GR9	90	620	70	483	15
GR12	70	483	20	345	18
GR23	120	828	110	760	10

Product Testing According to globally recognized standards, such as ASTM, AMS, ASME and provide third-party inspection reports, DNV accredited IOS 9001:2008 quality management system 100% titanium sponge to produce titanium ingot and 3 times melting to ensure the uniformity of chemical composition. For chemical composition inspection, not only inspect the titanium ingot, but also the semi finished products and finished products, just to ensure 100% qualified products before shipping. Mechanical property testing making sure all titanium products can satisfy mechanical features before delivery. Strict inspection when producing and finished products. Visual inspection to check surface quality, ensuring without flaw, black dot and any other defects. Ultrasonic Flaw Detection make sure they are no defect inside. Chemical Composition detection make sure all chemical component can meet your demands. Yield strength, tensile strength, elongation percentage reduction of area, Impact bending test, microstructure tests. Hardness testing, Penetrant testing, Radiographic testing etc. as per your requirements. product application Petroleum, Metallurgy, Chemical, Pharmacy, Marine Engineering, Racing Car, Motorcycle, Bicycle, Yacht, Outdoor Camping and Sports Equipment. Medical industry, aerospace, spaceflight, airplane, military,etc
FAQ 1.Are you a manufacturer or a trader?
We're a manufacturer with more than years of professional production experience.
2.Can you accept OEM?
Yes, OEM is acceptable. Just pls provide us with the drawing or sample, we will production totally according to your requirements.
3.Can you provide us with the design drawing?
Yeah, of course, we will provide you with the drawing after you paid or prepaid.
4.Can your factory produce products according to our drawings?
Yes, we can. Most products can be customized, including the Logo on products.
5.What kind of your packaging?
Neutral plywood or wooden box packaging or according to customer's requirements.
6.How long is your delivery time?Which ports are accepted for delivery?
Normally 30days after payment, and we promise we will deliver as soon as we can.It can be delivered from Qingdao, Tianjin, Shanghai, Guangzhou and other ports.
7.How can we get your price ?
A. We need below information to quote for you:
1). Product Name
2). Standard
3). Material Grade (Chemical Composition)
4). Dimension
5). Quantity
6). The Drawing for Special Parts

---
