We67k Hydraulic Press Brake, Press Brake, Plate Bending Machine

Product Description

We67k Hydraulic Press Brake, Press Brake, Plate Bending Machine
1. Equipped with special controller with automatic test and self-diagnosis.
2. Programming a product simply consists of introducing the characteristics of the material to be bent, the dimensions of the product and the necessary tooling & die.
3. The optimizing software searches for the best bending cycle.
4. RAM stroke(Y1, Y2) and backgauge (X, R, Z) are controlled by controller automatically, high productivity.
5. Adopting Electro-hydraulic proportional servo synchronization.
6. Optional point within stroke can be controlled. Repeat precision of Y axes: ± 0.01mm, Parallism: 0.02mm.
7. Strong ability of deviation resistance. Backgauge adopts ball-bearing screw and rolling guideway, quick speed and high repeat positioning precision.
8. X axes with resolution 0.1mm. Imports including linear transducer, pressure proportional valve and servo motor.
The models are available in variety of tounge from 40 ton up to 1000 ton and length from 2000 mm up to 8000 mm. The specifications below 300 ton refer to Series WC67Y. Any tailor-made are available on request.

Model	Nominal Pressure	Length of Table	Distance between Housings	Throt Depth	Stroke	Strokes	Open height	Main Motor	Weight	Overall Dimensions L× W× H
WE67K-200/6500	2000	6500	4850	320	200	≥ 3	465	15KW	27, 000	6585× 2100× 2900
WE67K-250/5000	2500	5000	4020	400	250	≥ 3	560	15KE	28, 000	5080× 2000× 3360
WE67K-300/5000	3000	5000	4010	400	250	≥ 3	560	15	29, 000	5100× 2600× 3400
WE67K-400/4000	4000	4000	3180	400	320	≥ 2.5	630	30	29, 500	4080× 2650× 3900
WE67K-400/5000	4000	5000	4000	400	320	≥ 2.5	630	30	34, 500	5100× 2650× 3900
WE67K-400/6000	4000	6000	4820	400	320	≥ 2.5	630	30	39, 500	6100× 2650× 3900
WE67K-500/6000	5000	6000	4820	400	320	≥ 2.5	630	30	59, 500	6100× 2800× 4600
WE67K-600/5000	6000	5000	4000	400	320	≥ 2.5	630	30	60, 000	5100× 2950× 4900
WE67K-600/6000	6000	6000	4880	400	320	≥ 2.5	630	30	66, 000	6100× 2925× 4900
WE67K-800/6000	8000	6000	4800	500	360	≥ 2	710	45	79, 000	6200× 4100× 4900
WE67K-800/7000	8000	7000	5600	500	360	≥ 2	710	45	85, 000	7200× 4100× 4900
WE67K-1000/6000	10000	6000	4800	500	450	≥ 1.5	800	50	139, 000	6300× 4400× 5800
WE67K-1000/8000	10000	8000	5600	500	450	≥ 1.5	800	50	150, 000	8300× 4400× 5800

---
