High Efficiency CNC Vertical Machining Centers (MV-650)

Product Description

LK MV Series Machinng Centers
Performance Features
Technical Parameters

MODEL	UNIT	MV-650
CNC Control System		Mitsubishi M80
3 axis Travel
X axis Travel	mm	650
Y axis Travel	mm	600
Z axis Travel	mm	560
Distance from Spindle Center to Table	mm	150-710
Spindle
Spindle Speed	rpm	Belt 8,000
Spindle Nose	BT	#40
Spindle Motor	kw	11/15
Table
Table Size	mm	850*600
T Slot (Width*No.*Pitch)	mm	18*5*100
Max. Table Capacity	kg	500
Rapid Travel
Rapid Travel (X/Y/Z)	m/min	36*36*36
Cutting Speed Rate	m/min	1-20
X/Y/Z Feed Motor	kw	2/2/3
Tool Magazine
Tool Change Type	-	Arm
Tool Capacity	set	24
Max. Tool Weight	kg	7
Max. Tool Length Distance	mm	250
Max. Tool Diameter	mm	Φ75/Φ150
Tool Change Time (T-T)	sec	2.3
Tool Change Time (C-C)	sec	3.5
Others
Compress Air Supply	kg/cm2	5-7
Machine Size	mm	3998*4111*2702
Net Weight	kg	5420

Products Machined by LK MV Series Machining Centers
Introduction to LK CNC Machining Centers
As a global machining center manufacturer, LK has developed several series of machining centers which can replace the labor so that improve the production efficiency. Their functions include cutting, tapping, milling, drilling and etc. The vertical series is mainly for the machining of high-precision medium and large parts, and the compact high-speed series is mainly for the machining of new-energy battery cases, LED panels, big boxes and other products.
LK MV Series Machining Centers is widely used in exact parts and toolings. With extraorinary flexibility in application amd highest efficiency in production, MV Series are in providing of customers' productivity.
Brief Introduction to LK GROUP
As one of the global leader in machine tool manufacturing, LK engages in the design, manufacture and sales of three featured products, i.e. die casting machines, plastic injection molding machines and CNC machining centers. LK not only has made the first magnesium alloy die-casting machine in China but also has set the standards for China's die-casting and injection-molding industries. With the state of the art facilities and technology, LK builds high-performance solutions to meet industry needs in the past 43 years.
As a global die-casting machine manufacturer in the world as well as China's major injection molding machine manufacturer, LK produces cold chamber die-casting machines with a clamping force from 130 to 9,000 tons, hot chamber die-casting machines with a clamping force from 8 to 400 tons and precision injection molding machines with a clamping force from 50 to 7,000 tons. The LK brand grows with the customers, with over 33,000 die casting machines which are running over the world, accounting for approximately 60% market share in China die casting industry, and remarkable market share in India, Brazil, Australia, South Africa, Thailand, Indonesia, Malaysia, Japan, USA, etc.
To further expand its footprint, LK acquired one of the world's leading die casting machine manufacturers, IDRA in 2008. Nowadays, LK has manufacturing bases in Shenzhen, Zhongshan, Ningbo, Shanghai, Fuxin, Kunshan, Taiwan and Italy. Meanwhile, LK has five technology R&D center, located in Edinburgh and Indiana in USA, Pune in India, Jakarta in Indonesia and Chongqing in China. To capture overseas markets, LK has established more than 60 sales and service centers in more than 20 countries in the world, which are ready to support customers from the initial idea and planning of production, up to training, consulting and the reconditioning of current equipment.
Company Workshop
LK, the global machining center manufacturer is at your service.

---
