| US$1,800.00-2,500.00 | 1 Piece (MOQ) |
| BENCH LATHE | CZ1340G/1 CZ1440G/1 | |
| Main data | Swing over bed | φ 330mm / φ 355mm |
| Swing over carriage | φ 195mm / φ 220mm | |
| Swing over gap | φ 476mm / φ 500mm | |
| Width of bed-way | 186mm | |
| Distance between centers | 1000mm | |
| Spindle | Taper of spindle | M. T. 5 |
| Spindle diameter | φ 38mm | |
| Step of speed | 8 Steps | |
| Range of speed | 70-2000 rpm | |
| Head | D1-4 | |
| Thread and feed system | Metric thread | 26kinds (0.4~7mm) |
| Inch thread | 34kinds(4~56T. P. I) | |
| Module thread | 16 kinds(0.35~5M. P) | |
| Diametral thread | 36 kinds(6~104D. P) | |
| Longitudinal feeds | 0.052~1.392mm (0.002" ~0.0548" ) | |
| Cross feeds | 0.014~0.38mm (0.00055" ~0.015" ) | |
| Main lead screw | Diameter lead screw | φ 22mm(7/8" ) |
| Pitch of lead screw | 3mm or 8T. P. I | |
| Saddle and carriage | Saddle travel | 1000mm |
| Cross travel | 170mm | |
| Compound travel | 74mm | |
| Tailstock | Barrel travel | 95mm |
| Barrel diameter | φ 32mm | |
| Taper of center | M. T. 3 | |
| Power | Motor power | 1.5KW (2HP) |
| Motor for coolant system' s power | 0.04KW (0.055HP) | |
| Shipment data | Machine(L× W× H) | 1920× 760× 760 (mm) |
| Stand(left) (L× W× H) | 440× 410× 700 (mm) | |
| Stand (right)(L× W× H) | 370× 410× 700 (mm) | |
| Machine | 510/565 (kgs) | |
| Stand | 70/75 (kgs) | |
| Loading qauntity/20" container | 22 pcs | |
