China Manufacturers Good Price Industrial Adjustable Beam Shelving Warehouse Cargo Goods Storage Rack Heavy Duty Metal Steel Structure Selective Pallet Racking

Product Description

Details Images
Load Test Our Safety Assurance The stability of our shelves and the safety of personnel are always our top priorities.
High-quality materials and Stringent Inspection Standards form the foundation of our shelf
stability.
High-Quality Steel:
We use premium Q235 cold-rolled steel from top steel manufacturer.
Q235 steel boasts excellent mechanical properties:
Yield Strength: Approximately 235 MPa
Tensile Strength: Ranging from 370-500 MPa
Elongation: Approximately 26% (at a 200mm gauge length)
In addition, we have specifically equipped safety accessories to ensure security.
Footplates: Footplates are fixed to the ground using expansion screws. Depending on the
load-bearing capacity, we provide both Type II Footplates and enclosed Footplates.
Guardrail: Mainly U-shaped (240mm long, 500mm high, 2.0mm thick), not in contact with the
shelves, anchored to the ground primarily to prevent forklifts from knocking down the shelves.
Rear Crossbeam: Rear crossbeams are installed at the back of the shelves to prevent goods
from falling off the shelves and provide additional safety protection for operators.
Safety Bolt: 7-shaped, inserted into the holes of the uprights to maintain the stability of the
beams.
Back Mesh: Installed on the sides of the shelves to prevent small items from scattering.
Pallet Stops: These devices prevent goods from sliding or rolling on the shelves, ensuring
that the goods are securely placed in the proper position.
Goods Dividers: Used to separate goods to prevent them from tilting or collapsing when
stacked.
Mesh Decking: Different-sized items can also be placed on the shelves, eliminating fire
hazards associated with wooden boards.
Pallet Supports: Increase beam support and prevent items from falling, available in two types:
straight and diagonal designs.
Diagonal Braces: Support structures between shelf uprights that increase the overall stability
of the shelves, reducing lateral deformation and shaking.
Cross Braces: These connectors can be installed between the horizontal beams of the
shelves to increase overall rigidity.
Signage and Warnings: Safety signs, warning signs, and instructions help operators use the
shelves correctly and remind them of safety precautions.
Row Spacer: Maintains stability between mainframes and sub-frames.
Shims: Provide shock absorption, reduce noise, adjust shelf height and horizontal angles,
and preventshelf sliding.

Products Support
Free Consultation	Yes, Any Questions You Can Consult With Free.
Support For Custom	Yes
Free Design	Yes, CAD/PDF/3D Drawing
Free Sample	Available (Delivery Cost By Buyer)
3D Sample	Yes, 1:1 3D Sample, Save Your Time And Cost of Trial and Error
Pre-installation	Yes
Capacity Test	Yes, If Needed.
OEM&ODM	Available
Lead Time	15-20 Days For Regular Pallet Racking, One Container
Installation Service	Yes, Submit the Installation Drawing Or Video, and send the Engineer To Your Site If Needed.
Maintenance Service	Yes, We Submit a Free Maintenance Guide.
Repair Service	Yes, We Submit Repair Services.

The following introduces you to different pallet racking components:
Upright: Upright plays an important role in connecting each beam of pallet racking and
broadening the entire storage space. Frame: the main role of the frame is to connect the beam and guarantee the whole pallet
racking more stability. Beam: beams ca n be u sed to get strong support for your pallet racking.
Base Plate: fix the bottom of pallet racking. Upright Protector: fix the upright columns to avoid the frame being unstable, and protect the
racks.
Shim: make the bottom of the pallet racking more flatter
Connecting Bolt: It is responsible for connecting the beams and frames
Customized Services
OKE Storage supports customization, such as drawing,color,package and size etc.
Why Choose Us
1.Strictly Racking Quality Inspection OKE Storage Systems has a professional quality inspection team consisting of 15 people, we
check the pallet racking quality for every producing step, it can guarantee the quality of your
racking during processing.
2.Advanced Production Equipment A variety of complete equipment to make sure the delivery time and quality are within our
control range. 3.The Best Racking Quality of Powder Coating OKE Storage via two times powerful pickling technology to make oxidize very well and
produce a layer of oxidation film on the steel surface, which can make the resin powder
adsorb better on the steel, No Other Supplier Match! Greatly increased your racking life.
Company Profile Company Introduction:
OKE Storage is dedicated to the production of racking storage, providing quality solutions for
saving your storage space and storage ways.
We have over 23 years of experience exporting our quality racking to over 85 countries
worldwide to date. Our fully automated, state-of-the-art technology provides the preconditions
for the production of the optimum racking.
We also offer a 10-year warranty to cover all your racking problems in the future. Most
importantly,we always put the customer first and provide the best possible service.
FAQ Q1:Is Selective Pallet Racking Same as the Teardrop Pallet Racks?
A1:Selective racking is the standard version. On the other hand, teardrop racks are just one
type of these racks.
Q2:Layout of Selective Pallet Racking?
A2:The layout of a selective rack is strict to one pallet deep. This limits you to only place two
back-to-back racks.
Q3:Can the Selective Pallet Racking be easily adjusted or expanded in the future?
A3:The beams are inserted into the uprights, making disassembly very convenient. The
spacing of each hole in the uprights is 50mm/75mm, and the minimum adjustment distance
for rack height is 50mm/75mm. You can extend the depth of the rack by adding additional
frames,typically up to 30 additional frames. However, intheory,it can be expanded indefinitely.
Q4:What Safety Accessories Are Included with the Selective Pallet Racking?
A4:Bottom angles, diagonal braces, horizontal braces, foot guards, guardrails, rear load
beams,safety bolts, back mesh, pallet stops, cargo dividers, mesh panels, pallet supports,
anti-roll drums,signage and warnings,intermediate struts, and shims are all included.
Q5:How Does the Selective Pallet Racking Ensure Proper Load Distribution and Stability?
A5:Our professional design team calculates and analyzes the rigidity, strength, and torque of
the steel,taking into account permanent, variable, and accidental loads, as well as the effects
of perforations, local buckling, global buckling, distortion buckling, and defects. In simple terms,
the design of beams and uprights helps distribute loads evenly. Diagonal and horizontal braces
provide stability to the structure.
Q6:What Products Are Suitable for Selective Pallet Racking?
A6:Pallet racking is suitable for storing a variety of large quantities of items, as well as
single-item bulk storage.For example, it can be used for storing food, clothing,pharmaceuticals,
parcels, packaging materials, automotive parts, and more. Recommend Products

---
