Automatic Drinking Mineral Water Beverage Filling Bottling Machine

Product Description

Full Set Complete Automatic PET Plastic Bottle Drinking Mineral Water Production Line
The machine is used for producing drinking water in PET bottle, such as pure water, mineral water,natural water etc.Adopting hanging-neck technology,it can transfer the plastic bottle more stably and faster. One machine can finish washing bottle, filling and capping three processes, sanitary and high-efficiency,High-quality filling valve guarantee the filling level precision.
Beverage Machinery-Equipment characteristics:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier. 2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough. 3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6.Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan\'s Mitsubishi, France Schneide, OMRON.

Washing Part ☆ Into bottle way is air conveyor direct connection with bottle dial. ☆ All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean. ☆ 304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing. ☆ 304/316 stainless steel washing pump make the machine more durable.

Filling Part ☆ 304/316 Stainless steel high precision filling nozzle☆ Filling volume adjustable in fine rank, same liquid level after filling☆ All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean☆ 304/316 stainless steel filling pump☆ Efficient spray nozzle rinse thoroughly and save water for flushing

Capping Part ☆ Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping☆ All 304/316 stainless steel construction☆ No bottle no capping☆ Automatic stop when lack of bottle☆ Capping effect is stable and reliable, Defective rate ≤0.2%

Model	CGF 8-8-3	CGF 14-12-5	CGF 16-16-5	CGF 24-24-8	CGF 32-32-10	CGF 40-40-12	CGF 50-50-15
Capacity (BPH)	1000-2000	3000-5000	6000-8000	8000-12000	12000-15000	16000-20000	20000-24000
Power supply	1.5 KW	1.5 KW	2.2 KW	3 KW	4 KW	7.5 KW	9.5 KW
Overall dimension	2000×1550×2650	2360×1770×2700	2760×2060×2700	2800×2230×2700	3550×2650×2700	4700×3320×2700	5900×4150×2700
Weight (KG)	1100	2500	3500	4200	5500	6800	7600

ABOUT SKYM
Zhangjiagang Sky Machine Co.,Itd is located at Leyu Economic Development Zone of Zhangjiagang City.Our Company was foundin 2008.We committed to do the World's most competitive liquid drink packaging manufacture suppliers.Focus on providing customers with safe,energy,saving,efficient equipment.And highquality,fast and personalized service. We sincerely invite businesses around the world to estabilish a professional relationship with us based on trust,benefits and the promising possibility for future development.

---
