Product Details
Product Description
Product Description
This series of one-component epoxy encapsulants is a heat-curing one-component epoxy encapsulant. It has the characteristics of stable storage, high bonding strength, good insulation performance, easy to use and strong applicability compared with two-component. It is suitable for potting relays, capacitors, flip-flops, IC circuits, computers, televisions, refrigerators, automobiles, motorcycles and other electronic components.
QLD5521 one-component epoxy encapsulant
The surface gloss can be bright or matte, the color can be white or black, the viscosity is low, it is suitable for potting small slits, and it cures in 30 minutes at 120°C.
QLD5522 one-component epoxy encapsulant
Colorless and transparent, good surface effect, curing at 100°C for 60 minutes.
5523 one-component epoxy encapsulant
The surface gloss can be bright or matte, the color can be white or black, the leveling effect is good, suitable for manual dispensing or machine automatic dispensing, and 90 minutes curing at 100°C.
QLD5524 one-component epoxy encapsulant
Black self-leveling, 80°C 90 minutes curing, low temperature curing type.
5526 one-component epoxy encapsulant
The surface gloss can be bright or matte, the color can be white or black, the leveling effect is good, suitable for manual dispensing or machine automatic dispensing, and 90 minutes curing at 120°C.
Performance indicators
Performance
| QLD5521
| QLD5522
| QLD5523
| QLD5524
| QLD5526
|
Color
| White/Black
| transparent
| White/Black
| Black
| White/Black
|
Viscosity (mpa.s,25ºC)
| 3000
| 5000
| 10000~20000
| 20000
| 30000~40000
|
Density (g/cm3)
| 1.2
| 1.2
| 1.3
| 1.3
| 1.4
|
Curing conditions
| 120ºC30min
| 100ºC60min
| 100ºC90min
| 80ºC90min
| 120ºC30min
|
Shear strength(steel/steel, Mpa)
| 13
| 13
| 15
| 13
| 15
|
Volume resistivity (Ω·cm, 25ºC)
| 1.3×1015
| 1.3×1015
| 1.5×1015
| 1.3×1015
| 1.5×1015
|
Surface resistivity (Ω, 25ºC)
| 1.2×1015
| 1.2×1015
| 1.3×1015
| 1.2×1015
| 1.3×1015
|
Dielectric strength (kv/mm)
| 20~22
| 20~22
| 20~22
| 20~22
| 20~22
|
Tensile strength(kg/mm2)
| 11
| 11
| 13
| 11
| 13
|
compressive strength (kg/mm2)
| 13
| 13
| 15
| 13
| 15
|
Shrinkage (%)
| <0.5
| <0.5
| <0.5
| <0.5
| <0.5
|
Glass transition temperature (ºC)
| 140
| 140
| 150
| 140
| 150
|
Processing
1. Take the glue out of the refrigerator and put it at room temperature to balance with the outside world for 1~2 hours.
2. Pour the glue into the components to be encapsulated or on the surface by hand or machine.
3. Slow heating and curing, which is conducive to the escape of bubbles and the penetration of glue to fill the gaps, to ensure excellent performance.
4. After use, the lid should be covered in time and stored in the refrigerator at 5°C.
Notes：
1. The validity period of this product is 3 months when stored at 5°C, and it can still be used if the viscosity is suitable after the storage period.
2. The curing test should be carried out according to the actual curing conditions and the characteristics of the processed components to ensure the best curing conditions suitable for specific products.
3. This product is non-dangerous goods, and it is stored and transported as non-dangerous goods.
4. Packing: 1kg.
>>
