Marine Double Drums Trawl Winch with 3ton Pulling Capacity

Product Description

Product introduce Marine Double Drums Trawl Winch with 3ton Pulling Capacity
Double drum winch
This winch is driven by hydraulic motor.
It consists of main shaft/ opening gears/ drum apparatus/ band brakes/ manual clutches/ frame and auto mechanical spooling devices. Drum apparatusIt is consisted of main shaft, sliding bearings, drum. gear wheel etc.
The drum connect to main shaft by sliding bears. Working principle of brakes:Braking: While braking, the brake bank will be tightened by level plate through locking screw.
Brake releasing: Loose the locking screw; The brake band will be loose.
If the brake bankd should be replaced, remove all the pins and bolts on the brake band. The brake band will be divided into two parts and can be taken off from the upper side of hub. And at last replace the old bands.
Rope capacity: 10mm x 600m steel wire rope
Rated working load capacity and speed: 3tons x 30m/min ( the first layer )
Braking load capacity: 9tons ( the first layer )
Manual brake, Manual clutch
With spooling device/ hydraulic station
With Changchai 4100 Diesel Engine
Hydraulic pump is running continously while main engine is working. Product Parameters

Brand	China Coal
Packing Details	standard wooden case packing
Delivery Time	5-10 days after your payment
Payment Terms	TT, Western Union and Paypal
Supply Ability	1000 sets per month
Minimum Order Quantity	1 set
Price Terms	FOB
Port	Qingdao,Ningbo,Shanghai,Shenzhen

---
