Product Description
Product Description
Product Description
Paper bag width
| 180-350mm/7.09-13.78inch
|
Paper bag bottom /gusset
| 70-150mm/2.76-5.91 inch
|
Paper tube length
| 290-600mm/11.42-23.62 inch
|
Paper length
| 530-1040mm/20.87-40.95inch
|
Paper width
| 290-600mm/11.42-23.62inch
|
Paper types and weight
| A: Art paper 128-200g
B:Art paper+pp:100-200g
C:White boardcard+pp:180-250g need die cut
D:Grey board card+pp:150-250g need die cut
|
Working speed
| 40-70pcs/min
|
Glue type
| Watery glue
(optional hot melt gule system to paste the bag tube)
|
Total power
| 10KW
|
Total weight
| 10T
|
Overall Dimension
(L×W×H)
| 14000×1800×1700mm
|
1,The characteristics of the product
PB-350/1040 type automatic paper bag making machine is the ideal equipment to take the flat papers with original colors or printed well as raw materials to make into paper bags with square bottoms.Its technique process is about:the flat papers after printing are delivered into the driving parts for positioning through automatic paper feeder and press line with rolling press device and then make one-side glue,folding and positioning and sticking and conveying device will convey them into the bottom position and conduct press horizontal line,open bottom,make glue and press togther and finally output finished bag products.
2,Shorten the cycle time
We set new standards to cut down the cycle time .Rapid cycle time improves capacity and lower production cost. INNOVO machine is one of the fastest ones among its like products.
3,Minimum wear and cost
Our engineering expertise and the long service life of our equipment guarantee higher capacity and lower cost while at the same time increase the output of quality products and reduce the unit cost.
4,High Quality
1)Reduce Power
3.7KW
For the power consumption,the main motor of INNOVO paper bag making machine is only 3.7kw,which is much lower than similar machines 10-20kw.Our machine is with the characteristics of reducing power consumption,paper sving costs,creating profits and more environmental protection.
2)Fastening
12.9Grades
High-end devices for the machine,even for each bolt,which using 12.9grades high strength bolts of more stess and more impact resistance.
3) Cooperation
NHK,SCHNEIDER,OMRON,MISIMI ETC.
From bearings to electrical apparatus, INNOVO company all use the international well –know high-quality brands,such as NHK,SCHNEIDER ETC.The machine performatce is more stable,mor efficient.
5,The applicable paper materials
Kraft paper,art paper, white paperboard and grey paperboard etc
(including laminting paper)
Packaging & Shipping
Packaging Details:standard wooden package
Delivery Detail:20 days
Our Services
1.15 years factory experience
2.10 years export experience
3.Over one hundred professional factory workers
4.100% quality guarantee,supply all kinds of certificates
5.Good after-sales serive,we send engineers to repair machine overseas.
6.Primary products:
Automatic High Speed Flute Laminater
ZXSCM Book Case Making Machine
650UV Coating Machine
ZX-650C Manual Paper Pasting Machine
Box Making Machine
Hot Melt Gluing Machine and Gluing Machine
Table Gluing Machine
Paper Pressing Machine.etc
FAQ
1.What is Innovo company machine warranty?----one year.
2.Does your machine with CE certificate?----Yes.
3.What is the production time while placing order?----About 7-30 days
4.What is the delivery time?----Within 7-30 days after get the payment.
5.Can Innovo company handle shipping for customers?----Yes.(Please provide us your requested seaport and we can check the shipping charge and arrange shipping for your order)
6.Does the packing strong?----Yes, of course! All of our export packing is with strong wooden case, all are confirm to export packing standard.
7.How about after-sales service process?----When your machine has problem, contact your sales and we will solve your problem as soon as possible.
8.Are you a manufacturer?----Yes, we are a manufacturer with 10-year experience and profession.
9.What is the minimum quantity for order?----Trial order 1 pc is acceptable, we done business step by step with high quality products and excellent services.
10Do you have stock product to sell?----Maybe, It depends on which machine you like.
11Do you inspect the finished products?----Yes, each step of production products will be picked out inspection by QC department before shipping.
12.What’s the payment term?----T/T 30% in advance, the balance paid against the copy of B/L. We accept payment via West Union too. You can choose as you like.
We are professional manufacturer since 2005. We believe our products will provide you with great business benefits and advantage.
Our faith:
1) Society's Avail First
2) Client's Avail First
3) Employee's Avail First
4) Enterprise's Avail Second
If you have any inquiry, please don’t hesitate to contact us. We will reply you at the first time as we can.
