C6251 Manual Horizontal Metal Gap Bed Lathe Machine

Product Description

C6251 Manual Gap bed Lathe Machine
Product Description
The guide way and all gears in the headstock are hardened and precision ground.
The spindle system is high rigidity and accuracy.
The machines have powerful headstock gear train, high rotating accuracy and smooth running with Iow noise
An overload safety device is provided on the apron.
Pedal or electromagnetic braking device.
Tolerance test certificate, test flow chart included
STANDARD ACCESSORIES
1 Three Jaw Chuck and Adapter
2 Four Jaw Chuck and Adapter
3 Face Plates
4 Steady Rest
5 Follow Rest
6 Oil Gun
7 Thread Chasing Dial
8 Operation Manual
9 One set of Wrenches
10 MT 7/5 Sleeve and MT 5 Center
SPECIAL ACCESSORIES
1 Driving Plate
2 Quick Change Tool Post
3 Taper Turning Attachment
4.variable speed
Product main technical specifications:

SPECIFICATION	C6251
Swing over red	510mm(20")
Swing over cross slide	305mm(11-7/8")
Swing in gap	735mm(29")
Length of gap	200mm(8")
Distance between centers	1000mm(60")/1500mm(60")/2000mm(80")/3000(120")
Width of bed	350mm(13-3/4")
Spindle nose	D1-8
Spindle bore	80mm(3-1/8")
Taper of spindle bore	No.7Morse
Range of spindle speed	12 changes 25-1600r/min
Max travel of compound rest	130mm(5-1/8")
Max travel of cross slide	316mm(12-15/16")
Leadscrew pitch	6mm Or 4T.P.L
Max.section of tool	25×25mm(1×1")
Longitudinal feeds range	35kinds 0.059-1.646mm/rev(0.0022"-0.0612"/rev)
Cross feeds range	35kinds 0.020-0.573mm(0.00048"-0.01354")
Metric threads range	47kinds0.2-14mm
Inch threads range	60kinds2-112T.P.L
Diametrical pitches range	50kinds4-112D.P.
Module pitches range	39kinds0.1-7M.P.
Dia of tailstock sleeve	75mm(3")
Travel of tailstock sleeve	180mm(7")
Morse taper of tailstock sleeve	No.5Morse
Cross adjustment	±13mm(±1/2")
Power of main motor	7.5kw(10HP)3PH
Power of coolant pump	0.1kw(1/8HP),3PH
Overall dimension(L×W×H)	239/284/334/434×115×143cm
Packing size(L×W×H)	245/290/340/440×115×143cm
Net weight/Gross weight	2035/2415 2160/2550 2435/2840 2805/3270

Detailed Photos
Company Profile
What We Do?
Our main products are :
CNC Lathe Machine, CNC machining center, CNC Milling Machine, CNC Turning Center, Lathe machine, Milling machines,,Drilling machine, Sawing machine, Grinding machine and other metal-working machines and accessories.
Our Machines Application Fields:
1.Aviation industry: 5-axis machining centers, horizontal and gantry machining centers, precision CNC lathes, etc. can be used to process parts such as aircraft wings, fuselages, empennages and engines
2.Railway locomotive manufacturing industry: CNC lathes, vertical and horizontal machining centers, and five-axis machining centers can process high-speed rail locomotive bodies, axles, wheels and other parts
3.Mold manufacturing: high-speed CNC milling machine, high-precision CNC machining center, precision grinding machine can process automotive panel molds, die-casting molds, forming extrusion molds, etc.
4.Power equipment manufacturing industry: For power generation equipment, heavy CNC gantry milling machines, large floor milling machines, large CNC lathes,
In addition, our machine tool products can also be used in weapon manufacturing, electronic information equipment manufacturing, metallurgical equipment manufacturing.

WHY CHOOSE US?
QUALITY COMMITMENT
Company is committed to bring efficient, high precision and stability to all users by insisting on providing our customers with high quality machines.Company machines passed ISO, CE Certificates.
SERVICE SUPPORT
The warranty period is general 13 months after B/L date. During the warranty period, if the parts are damaged because of itself quality problems,except human factors and improper operation, we will provide free replacement parts. Meanwhile, the machine should be under normal operation according to Operation Manual.
Company also provide provide online technical support, voice and video guidance.
Our Facotry
MANUFACTURER CAPABILITY
The company has purchased high-precision and high-efficiency advanced equipment from well-known domestic and foreign brands, and the company's machining and production technology level has been continuously improved, resulting in a continuous increase in production capacity. Company provide first-class machines to to meet the needs of domestic and foreign customers.
R&D CENTER
Company collected first-rate professionals in domestic machine tool trade and established long-term technical cooperative relations with other famous machine manufactures. Meanwhile, companmy pays more attention to introducing advanced foreign technology, and makes great efforts to achieve technical renovation and develop market oriented highly sophisticated products.
Company provide comprehensive cnc machines and manual machines to global customers.
Whether you are an end user, a dealer, or a machining factory, you can send your technical requirements, specifications, drawings, and we will provide the most and we will provide the most suitable machine or a comprehensive processing line solution.

After Sales Service
SERVICE SUPPORT
From the moment you become part of the DECHANG, we are fully dedicated to guiding you, answering your questions and supporting your business. You can rest assured that with DECHANG, you always have a trusted partner to guide you every step of the way. See how our Technical Support services can answer your questions and help you solve your most pressing issues.

1.Warranty

The warranty period is general 13 months after B/L date. During the warranty period, if the parts are damaged because of itself quality problems,except human factors and improper operation, we will provide free replacement parts. Meanwhile, the machine should be under normal operation according to Operation Manual.
2.Quick Response

Our top-notch, expert technical support specialists are there for you seven days a week, 24 hours a day, so you can always count on us to provide help when you need it most.
3.Online Technical Support

On the Whatsapp or Wechat, our technician and sales will deliver solution by taking video and words instructions.
4.Overseas Commissioning and Installation
This is a paid service. If an engineer is required for overseas installation and debugging, please contact the salesperson to obtain the cost

FAQ
1: Where is your company A: Our company is located in Tengzhou City, Shandong Province.2: What about your warranty?A: Warranty is one year. During warranty time, if the parts are damaged because of Nonhuman factors, we will send new replaced parts for free3: How do you offer after-sale service?A: We usually offer technical support online by wechat or whatsapp. Customer describe the problems and send videos and pictures, our technician will help to solve the problems4. What is your standard package? A: Our package is export standard plywood case with pallet.5: What's the Payment Terms? A: T/T, 30% initial payment when order, 70% balance payment before shipment; 6: What's the MOQ? A: 1 set.

---
